Vibro-Meter VM600 MPC4 200-510-076-114 Modules

Technical Dossier

Product Details And Specifications

Vibro-Meter VM600 Series Technical Notes

The Evolution of VM600 Architecture

The VM600 platform succeeded the earlier Vibro-Meter VM500 series, which used analog signal conditioning with limited digital integration. The VM600 introduced a fully digital backplane bus (the VME-based rack architecture) with deterministic scan rates suitable for overspeed and thrust position protection. Early VM600 racks (circa late 1990s) used the RPS600 rack power supply and supported up to 12 I/O slots per chassis. The introduction of the MPC4 (Machinery Protection Card, 4-channel) represented a consolidation from earlier single- and dual-channel cards, reducing rack density requirements by up to 50%.

Subsequent firmware revisions introduced IEC 61511 compliance pathways and expanded communication options via the CMC16 and IOCC8 interface cards, enabling integration with DCS platforms including Emerson DeltaV, Honeywell Experion, ABB 800xA, and Yokogawa CENTUM VP via Modbus RTU/TCP and OPC DA/UA. The VM600 platform entered its mature/sustaining phase around 2015, with Meggitt confirming continued spare parts availability and repair services through authorized service centers. New installations increasingly use the successor Meggitt Vibro-Meter VibroSight platform, but the VM600 installed base remains extensive, making long-term spare parts sourcing a critical operational requirement for asset owners.

VM600 Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly deployed modules within the VM600 platform. Each entry reflects a distinct functional role within the rack architecture.

Machinery Protection Cards (MPC)

• VM600 MPC4 200-510-076-114: 4-channel machinery protection card, configurable for vibration, position, and speed measurement; API 670 compliant.
• VM600 MPC4 200-510-076-100: Standard 4-channel MPC4 variant; earlier hardware revision with analog output configuration.
• VM600 MPC4 200-510-076-110: MPC4 mid-series revision; updated FPGA firmware for improved relay response time.
• VM600 MPC4 200-510-076-120: MPC4 variant with extended temperature range for harsh environment enclosures.

Rack Power Supplies (RPS)

• VM600 RPS600A 200-510-050-100: Redundant rack power supply, 24 VDC input, supports dual-PSU hot-swap configuration.
• VM600 RPS600B 200-510-050-110: Updated RPS with enhanced EMC filtering for offshore and nuclear environments.

I/O and Communication Cards

• VM600 IOCC8 200-510-080-100: 8-channel I/O concentrator card; aggregates channel data for DCS transmission via Modbus TCP.
• VM600 CMC16 200-510-082-100: 16-channel communication and monitoring card; supports OPC DA server interface.
• VM600 CMC16 200-510-082-110: CMC16 revision with OPC UA support and enhanced cybersecurity hardening.
• VM600 RCOM 200-510-085-100: Rack communication module; provides Ethernet backbone connectivity between VM600 racks.

Speed and Phase Reference Cards

• VM600 SPC4 200-510-078-100: 4-channel speed and phase reference card; supports keyphasor inputs for dynamic balancing and overspeed trip.
• VM600 SPC4 200-510-078-110: SPC4 revision with dual-redundant keyphasor input processing.

Relay Output Cards

• VM600 ROC8 200-510-090-100: 8-channel relay output card; SPDT relay contacts rated 5 A at 250 VAC; used for alarm and trip output wiring.
• VM600 ROC8 200-510-090-110: ROC8 with enhanced contact isolation for SIL 2 loop configurations.

Analog Output Cards

• VM600 AOC8 200-510-092-100: 8-channel analog output card; 4–20 mA outputs for DCS historian integration.
• VM600 AOC8 200-510-092-110: AOC8 with HART protocol overlay for smart transmitter compatibility.

Sourcing Hard-to-Find & Obsolete VM600 Parts

Q: How are RFQ terms confirmed?
A: Quantity, required condition, documentation needs, destination and sourcing route are confirmed during RFQ review before quotation.
