Allen-Bradley PowerFlex 755 AC Drives: 20F11NC022JA0NNNNN

Name: Allen-Bradley PowerFlex 755 AC Drives: 20F11NC022JA0NNNNN
Brand: Allen-Bradley

Model: 20F11NC022JA0NNNNN

Brand Allen-Bradley

Series PowerFlex 755

Model 20F11NC022JA0NNNNN

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Allen-Bradley PowerFlex 755 Series Technical Notes

The Allen-Bradley PowerFlex 755 (catalog prefix: 20F) is a high-performance AC variable frequency drive engineered for demanding industrial applications. Deployed extensively across global heavy industries — including petrochemical refineries, nuclear power auxiliary systems, offshore platforms, and continuous-process chemical plants — the PowerFlex 755 occupies a tier-1 position in Rockwell Automation's drive portfolio. Its architecture supports vector control, permanent magnet motor control, and integrated safety (SIL 2 / PLd), making it a standard specification in facilities governed by IEC 61508 and ISO 13849. Frame sizes range from 1 through 8, covering output current ratings from 1 A to 1200 A and voltage classes of 400 V, 480 V, 600 V, and 690 V AC. The drive's modular I/O and option card bay design allows field-configurable expansion without drive replacement, a critical factor for facilities operating under strict change-management protocols.

The Evolution of PowerFlex 755 Architecture

The PowerFlex 755 was introduced by Rockwell Automation in 2008 as the successor to the PowerFlex 700 (20B/20C prefix) and PowerFlex 700H/S series. The original 755 platform standardized on a common control architecture shared with the PowerFlex 750-Series (which also includes the PowerFlex 753, prefix 20G). Key architectural milestones:

2008–2012 (Gen 1): Base platform launch. EtherNet/IP adapter (20-750-ENETR) introduced as primary network interface. DriveLogix embedded controller option (20-750-DCLX) enabled tight integration with Logix5000 PLC ecosystem. Dual-port EtherNet/IP support enabled Device Level Ring (DLR) topology.

2013–2016 (Gen 2): Introduction of TotalFORCE® control technology. Enhanced flux vector and permanent magnet motor support added. Safe Speed Monitor (20-750-S1) and Safe Torque Off (STO) options certified to SIL 2. Expanded frame 7 and 8 availability for high-power applications above 250 kW.

2017–Present (Gen 3 / Active): Integration with FactoryTalk Analytics. Predictive diagnostics via embedded vibration monitoring. Compatibility with Studio 5000 Logix Designer v30+. The PowerFlex 755T (20-750T prefix) sub-series introduced with integrated DC bus common architecture for multi-drive systems, reducing harmonic distortion without external filters.

Compatibility note: Option cards from the PowerFlex 700 series are not interchangeable with PowerFlex 755 bays. The 750-Series option card form factor is shared between 753 and 755 drives, but firmware versions must be validated before cross-installation.

PowerFlex 755 Full Catalog & Functionalities (SKU List)

The following catalog numbers represent verified, commonly stocked PowerFlex 755 configurations. SKUs are organized by functional category.

AC Drive Main Units (Frame 1–8)

20F11NC022JA0NNNNN: PowerFlex 755, 480V, 3-phase, 22A, Frame 2, IP20, no options installed — the subject unit of this listing.
20F11NC011JA0NNNNN: PowerFlex 755, 480V, 3-phase, 11A, Frame 1, IP20, standard base configuration.
20F11NC030JA0NNNNN: PowerFlex 755, 480V, 3-phase, 30A, Frame 2, IP20, general-purpose vector control.
20F11NC052JA0NNNNN: PowerFlex 755, 480V, 3-phase, 52A, Frame 3, IP20, mid-range pump/fan duty.
20F11NC077JA0NNNNN: PowerFlex 755, 480V, 3-phase, 77A, Frame 4, IP20, conveyor and compressor duty.
20F11NC104JA0NNNNN: PowerFlex 755, 480V, 3-phase, 104A, Frame 4, IP20, high-inertia load applications.
20F11NC156JA0NNNNN: PowerFlex 755, 480V, 3-phase, 156A, Frame 5, IP20, heavy industrial duty.
20F11NC180JA0NNNNN: PowerFlex 755, 480V, 3-phase, 180A, Frame 5, IP20, large pump/compressor.
20F11NC248JA0NNNNN: PowerFlex 755, 480V, 3-phase, 248A, Frame 6, IP20, high-power process drive.
20F11NC302JA0NNNNN: PowerFlex 755, 480V, 3-phase, 302A, Frame 6, IP20, refinery/chemical plant standard.
20F11NC415JA0NNNNN: PowerFlex 755, 480V, 3-phase, 415A, Frame 7, IP20, large motor drive above 200 kW.
20F11NC506JA0NNNNN: PowerFlex 755, 480V, 3-phase, 506A, Frame 7, IP20, high-current industrial application.
20F11NC650JA0NNNNN: PowerFlex 755, 480V, 3-phase, 650A, Frame 8, IP20, maximum frame standard voltage.
20F31NC022JA0NNNNN: PowerFlex 755, 600V, 3-phase, 22A, Frame 2, IP20, North American 600V grid variant.
20F51NC022JA0NNNNN: PowerFlex 755, 690V, 3-phase, 22A, Frame 2, IP20, European high-voltage grid variant.

Option Cards & Expansion Modules (750-Series Compatible)

20-750-ENETR: Dual-port EtherNet/IP adapter, DLR-capable, primary network interface for Logix integration.
20-750-DCLX: DriveLogix embedded controller, Logix5000-compatible, onboard PLC for standalone drive control.
20-750-S1: Safe Speed Monitor option card, SIL 2 / PLd certified, hardwired safety input interface.
20-750-PBUS: PROFIBUS DP adapter, 12 Mbps, for legacy DCS integration in European process plants.
20-750-DNET: DeviceNet adapter, for integration with legacy Allen-Bradley PLC-5 and SLC 500 systems.

Sourcing Hard-to-Find & Obsolete PowerFlex 755 Parts

While the PowerFlex 755 platform remains in active production as of 2026, specific catalog configurations — particularly early Gen 1 frame assemblies, discontinued option cards (e.g., 20-750-PBUS in certain markets), and legacy control boards — have entered limited-availability or end-of-life status through Rockwell Automation's standard distribution channels.

Quality Control for the PowerFlex 755 Range

PowerFlex 755 drives present specific test challenges due to their multi-bay option card architecture, integrated safety circuits, and EtherNet/IP firmware dependencies. DriveKNMS applies the following verification protocol to all PowerFlex 755 units processed through its facility:

Power Stage Verification: Full load current test at rated voltage using calibrated motor load bank. IGBT gate drive waveform analysis via oscilloscope. DC bus capacitance measurement against OEM specification (tolerance: ±10%).

Control Board Functional Test: Firmware version identification and logging. HIM (Human Interface Module) communication verification. Parameter backup and restore cycle to confirm NVRAM integrity.

Option Card Slot Integrity: Each populated option bay tested for correct enumeration on EtherNet/IP network. Safe Torque Off (STO) circuit continuity test per IEC 62061 test procedure. PROFIBUS/DeviceNet adapters tested against live network segment where applicable.

Environmental & Mechanical Inspection: Thermal imaging of power components under load. Fan bearing condition assessment (acoustic and vibration). Enclosure integrity check for IP20/IP54 rating compliance.

Continue The Model Path

Use system, brand and series routes to compare related published models.

Move from this exact model into the matching system hub, brand archive, model-family archive or lifecycle sourcing route before sending a final RFQ list.
