Allen-Bradley Kinetix 5700 Modules: 2198-S160-ERS3

Name: Allen-Bradley Kinetix 5700 Modules: 2198-S160-ERS3
Brand: Allen-Bradley

Model: 2198-S160-ERS3

Brand Allen-Bradley

Series Kinetix 5700

Model 2198-S160-ERS3

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Allen-Bradley Kinetix 5700 Series Technical Notes

The Allen-Bradley Kinetix 5700 servo drive system, manufactured by Rockwell Automation, is a high-performance, multi-axis motion control platform deployed across the most demanding segments of global heavy industry. Installed in continuous-process environments including petrochemical refineries, nuclear power auxiliary systems, automotive body-in-white lines, and large-format packaging machinery, the Kinetix 5700 series represents Rockwell's current flagship EtherNet/IP-native servo architecture. Its dual-axis and single-axis inverter topology, combined with a shared DC bus infrastructure, allows engineers to achieve regenerative energy sharing across drive nodes — a critical requirement in high-cycle, high-inertia applications. The 2198-S160-ERS3 is a single-axis inverter module rated at 160A continuous output current, designed for integration into the 2198 DC-bus power rail system with EtherNet/IP (ERS3) communication.

The Evolution of Kinetix 5700 Architecture

Rockwell Automation's servo drive lineage progressed through several distinct generations before arriving at the Kinetix 5700 platform. The Ultra 3000 (2098-DSD series) represented the early standalone digital servo era, followed by the Kinetix 6000 (2094 series) which introduced the shared DC bus concept on a SERCOS III backbone. The Kinetix 6500 extended this with EtherNet/IP connectivity but retained a separate power supply topology. The Kinetix 5500 (2198-Hxxx) introduced a more compact, single-cable (2090-CSxM1DF) motor interface and native Studio 5000 integration. The Kinetix 5700 (2198-Sxxx / 2198-Dxxx) superseded the 5500 for high-power applications, introducing a true regenerative bus supply (2198-RPxxx), higher current ratings up to 260A per axis, and dual-port EtherNet/IP with Device Level Ring (DLR) support. Compatibility between generations is not direct — 2094-series power rails are electrically and mechanically incompatible with 2198-series bus bars. Migration from Kinetix 6000 to Kinetix 5700 requires new power infrastructure, new motor cables, and Studio 5000 v30 or later. The ERS3 communication standard (used in the 2198-S160-ERS3) denotes the third-generation EtherNet/IP drive profile, supporting CIP Motion and integrated safety over the same network port.

Kinetix 5700 Full Catalog & Functionalities (SKU List)

Single-Axis Inverter Modules (2198-Sxxx)

2198-S086-ERS3: Single-axis inverter, 86A continuous, EtherNet/IP ERS3, standard safety
2198-S130-ERS3: Single-axis inverter, 130A continuous, EtherNet/IP ERS3, standard safety
2198-S160-ERS3: Single-axis inverter, 160A continuous, EtherNet/IP ERS3, standard safety
2198-S263-ERS3: Single-axis inverter, 263A continuous, EtherNet/IP ERS3, standard safety
2198-S086-ERS4: Single-axis inverter, 86A, ERS4 profile, integrated STO/SS1/SLS safety
2198-S130-ERS4: Single-axis inverter, 130A, ERS4 profile, integrated functional safety
2198-S160-ERS4: Single-axis inverter, 160A, ERS4 profile, SIL 2 / PLd safety functions
2198-S263-ERS4: Single-axis inverter, 263A, ERS4 profile, highest-current single-axis node

Dual-Axis Inverter Modules (2198-Dxxx)

2198-D006-ERS3: Dual-axis inverter, 6A per axis, compact footprint, ERS3 communication
2198-D012-ERS3: Dual-axis inverter, 12A per axis, standard mid-range dual-axis node
2198-D020-ERS3: Dual-axis inverter, 20A per axis, ERS3, common in servo press applications
2198-D032-ERS3: Dual-axis inverter, 32A per axis, ERS3, high-cycle packaging lines
2198-D057-ERS3: Dual-axis inverter, 57A per axis, ERS3, heavy-duty dual-axis configuration
2198-D006-ERS4: Dual-axis inverter, 6A per axis, ERS4 safety profile, STO per axis
2198-D032-ERS4: Dual-axis inverter, 32A per axis, ERS4, integrated safe motion monitoring

Bus Supply & Power Infrastructure (2198-RPxxx / 2198-Pxxx)

2198-RP088: Regenerative bus supply, 88kW, active front-end, unity power factor
2198-RP200: Regenerative bus supply, 200kW, for large multi-axis systems
2198-P031: Passive converter bus supply, 31kW, non-regenerative entry-level power
2198-P070: Passive converter bus supply, 70kW, standard multi-axis power rail

Accessories & Communication

2198-CAPMOD-2240: Capacitor module, 2240µF, DC bus ride-through and energy storage
2198-DCBUSCOND-RP312: DC bus conditioner for regenerative supply systems
2198-H040-ERS3: Kinetix 5500 single-axis (legacy, for cross-reference only)

Continue The Model Path

Use system, brand and series routes to compare related published models.

Move from this exact model into the matching system hub, brand archive, model-family archive or lifecycle sourcing route before sending a final RFQ list.
