Applied Materials E7627/Z Modules: 0040-49884 E7627/Z 0150-00947

Technical Dossier

Product Details And Specifications

Applied Materials E7627/Z Series Technical Notes

The Evolution of E7627/Z Architecture

Applied Materials' board-level assemblies within the E7627/Z lineage evolved across multiple equipment generations spanning the late 1990s through the 2010s. Early variants were designed for VME-bus and proprietary backplane architectures used in first-generation Centura platforms. As equipment transitioned to PCI-based and later embedded PC control architectures, board designs were revised to accommodate higher-speed data buses, improved EMI shielding, and RoHS-compliant component sourcing. The /Z suffix in the part number typically denotes a revised or alternate-source component qualification, meaning the board may be functionally equivalent to a non-/Z variant but manufactured with approved substitute components. Compatibility between /Z and non-/Z variants must be verified against the specific equipment BOM and software revision. Many E7627/Z assemblies are now in the mature-to-end-of-life phase of their product lifecycle, with Applied Materials no longer offering new manufacture. This makes third-party refurbished and tested inventory the primary sourcing channel for ongoing fab maintenance.

E7627/Z Full Catalog & Functionalities (SKU List)

The following Applied Materials part numbers are associated with the E7627/Z board assembly family and related PCB sub-assemblies used across compatible equipment platforms. Each entry reflects a distinct configuration, revision, or functional variant:

0040-49884 E7627/Z 0150-00947: Primary PCB assembly, embedded control sub-system, 200/300mm platform compatible.
0040-49884: Base assembly part number; top-level BOM reference for E7627/Z board.
0150-00947: Sub-assembly or daughter board reference paired with 0040-49884 main board.
0040-76502: Alternate E7627-series control board, Centura CVD chamber interface.
0040-76503: Revised spin of 0040-76502; updated component sourcing, same form/fit/function.
0040-91956: Power regulation PCB assembly, E7627 platform, 24VDC rail output.
0040-91957: Dual-rail power board variant; used in high-density I/O configurations.
0040-36095: Signal conditioning board, analog input processing, E7627 backplane compatible.
0040-36096: Digital I/O expansion module; 32-channel DI/DO, E7627 bus interface.
0040-09578: Communication adapter board; RS-422/RS-485 interface, chamber-to-host link.
0040-09579: Fiber optic communication variant of 0040-09578; noise-immune data link.
0040-22714: Interlock and safety relay PCB; hardwired safety logic, E7627 chassis mount.
0040-22715: Expanded interlock board; additional relay channels for multi-zone chambers.
0040-55381: RF match network control board; used in etch and CVD plasma systems.
0040-55382: Updated RF control PCB; compatible with 13.56 MHz and 2 MHz dual-frequency systems.
0040-68741: Temperature control module; thermocouple input, PID output, E7627 rack mount.
0040-68742: Multi-zone temperature board; 8-channel TC input, used in Producer platform.
0040-77210: Pressure transducer interface board; 0–10V analog output, Baratron compatible.
0040-77211: Dual-channel pressure interface; supports two independent MFC/pressure sensor inputs.

Sourcing Hard-to-Find & Obsolete E7627/Z Parts

Q: How is condition confirmed before quotation?
A: Available condition, photos, test records and documentation are checked according to the requested model and sourcing channel before a formal RFQ response.
