Bently Nevada 32000 Series Modules - 32000-16-05-05-080-03-02

Technical Dossier

Product Details And Specifications

Bently Nevada 32000 Series Technical Notes

The Bently Nevada 32000 Series proximity probe system represents one of the most widely deployed eddy-current sensing platforms in global heavy industry. Installed across petrochemical refineries, nuclear power stations, offshore platforms, and large-scale rotating machinery facilities, the 32000 Series provides continuous, non-contact measurement of shaft radial vibration, axial position, and differential expansion. Its modular architecture — separating the probe, extension cable, and proximitor into discrete, field-replaceable components — has made it the reference standard for API 670-compliant machinery protection systems for over three decades. The system operates on the 200 mV/mil (7.87 V/mm) output scale, ensuring direct compatibility with Bently Nevada 3300, 3500, and ADAPT.wind monitoring platforms.

32000 Series Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly stocked configurations within the 32000 Series. Modules are grouped by functional category.

Proximity Probes (Metric, 5mm Tip)

• 32000-16-05-05-080-03-02: Metric proximity probe, 5mm tip, 80mm cable, standard housing assembly
• 32000-16-05-05-050-03-02: Metric proximity probe, 5mm tip, 50mm cable, standard housing assembly
• 32000-16-05-05-100-03-02: Metric proximity probe, 5mm tip, 100mm cable, extended housing assembly
• 32000-16-05-05-030-03-02: Metric proximity probe, 5mm tip, 30mm cable, compact housing assembly
• 32000-16-05-14-080-03-02: Metric proximity probe, 14mm extended tip, 80mm cable, standard housing
• 32000-16-05-14-050-03-02: Metric proximity probe, 14mm extended tip, 50mm cable, standard housing

Extension Cables (Metric)

• 32000-90-05-05-050-02-00: 5mm extension cable, 5m length, standard jacket, metric termination
• 32000-90-05-05-100-02-00: 5mm extension cable, 10m length, standard jacket, metric termination
• 32000-90-05-05-150-02-00: 5mm extension cable, 15m length, standard jacket, metric termination
• 32000-90-05-05-200-02-00: 5mm extension cable, 20m length, standard jacket, metric termination
• 32000-90-05-05-050-03-00: 5mm extension cable, 5m length, armored jacket, high-temperature rated
• 32000-90-05-05-100-03-00: 5mm extension cable, 10m length, armored jacket, high-temperature rated

Proximitor Modules (Signal Conditioners)

• 32000-00-05-05-02-00: Standard proximitor, 5mm system, -24 VDC supply, 200 mV/mil output scale
• 32000-00-05-05-03-00: Temperature-compensated proximitor, 5mm system, extended range -35°C to +85°C
• 32000-00-05-14-02-00: Proximitor for 14mm extended probe systems, -24 VDC, panel-mount housing
