Bently Nevada 3300/25-XX-15-15-00-00-03-02

Name: Bently Nevada 3300/25-XX-15-15-00-00-03-02
Brand: Bently Nevada

Model: 3300/25-XX-15-15-00-00-03-02

Brand Bently Nevada

Series 3300

Model 3300/25-XX-15-15-00-00-03-02

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Bently Nevada 3300 Series Technical Notes

The Evolution of 3300 Series Architecture

The 3300 Series was introduced as a successor to the earlier Bently Nevada 3100 and 3200 platform families, transitioning from discrete analog monitoring to a fully integrated rack-based modular system. Early 3300 configurations relied on individual transducer interface modules with hardwired relay outputs. Mid-generation revisions introduced the Keyphasor interface and expanded the communication bus to support 4–20 mA analog outputs compatible with plant DCS historians. Later variants incorporated dual-channel redundancy and configurable alert/danger setpoints via software, replacing manual potentiometer-based calibration. The 3300 Series has now entered the mature/end-of-life phase of its product lifecycle. Bently Nevada's current platform is the System 1 / 3500 Series. However, the 3300 Series remains in active service at thousands of facilities globally, and OEM-equivalent replacement modules, tested spare boards, and long-term maintenance support remain commercially available through specialist distributors such as DriveKNMS.

3300 Series Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly sourced modules within the Bently Nevada 3300 Series. Each entry reflects a distinct functional role within the rack system.

3300/25-XX-15-15-00-00-03-02: Dual-channel power supply module, rack-mount format, 15 VDC output rails, redundancy-capable configuration.

3300/10-01-00-00: Single-channel proximitor interface module, 5 mm gap range, standard Keyphasor input.

3300/10-02-00-00: Dual-channel proximitor interface, radial vibration measurement, configurable alert setpoints.

3300/15-01-00-00: Axial position monitor module, thrust bearing displacement measurement, 4–20 mA output.

3300/16-01-00-00: Differential expansion monitor, high-resolution displacement tracking for turbine casings.

3300/20-01-00-00: Velocity monitor module, seismic transducer input, peak-hold and RMS output modes.

3300/25-01-00-00: Standard power supply module, single output rail, non-redundant rack configuration.

3300/46-01-00-00: Keyphasor module, once-per-revolution reference signal conditioning, TTL output.

3300/50-01-00-00: Tachometer/speed monitor module, overspeed detection, relay trip output.

3300/55-01-00-00: Temperature monitor module, thermocouple and RTD input, configurable engineering units.

3300/60-01-00-00: Process variable monitor, 4–20 mA input, configurable high/low alert thresholds.

3300/65-01-00-00: Relay output module, SPDT contacts, configurable latching/non-latching trip logic.

3300/70-01-00-00: Communication interface module, RS-232/RS-485 serial output, DCS integration.

3300/75-01-00-00: System rack backplane module, 19-inch rack format, passive bus distribution.

3300/80-01-00-00: Barrier/isolator interface module, intrinsically safe zone separation, ATEX-compatible.

3300/90-01-00-00: Dual-channel vibration monitor, high-frequency response, bearing fault detection.

3300/95-01-00-00: Rack termination and I/O marshalling module, field wiring interface, screw terminal block.
