Bently Nevada 3300 NSv Proximity Probes: 330901-00-90-10-01-05

Technical Dossier

Product Details And Specifications

Bently Nevada 3300 NSv Series Technical Notes

The Bently Nevada 3300 NSv Series represents one of the most widely deployed eddy-current proximity probe systems in global heavy industry. Installed across petrochemical complexes, nuclear power stations, offshore platforms, LNG terminals, and large-scale rotating machinery facilities, the 3300 NSv system provides continuous, non-contact measurement of shaft radial vibration, axial position, differential expansion, and eccentricity. Its architecture conforms to API 670 machinery protection standards, making it the reference system for turbomachinery monitoring in critical process environments. The series operates on a triaxial measurement philosophy, with probe, extension cable, and proximitor forming a calibrated system that must be sourced and replaced as matched sets to maintain measurement accuracy within ±1% of full-scale output.

The Evolution of 3300 NSv Architecture

The 3300 NSv series is the direct successor to the Bently Nevada 3300 XL and the earlier 3300 5mm/8mm probe families. The original 3300 series was introduced in the 1980s as a modular eddy-current measurement platform. The XL generation introduced extended temperature range and improved EMI shielding for harsh environments. The NSv (Non-Standard Voltage) variant was developed to address installations requiring tighter output voltage tolerances and improved linearity across extended gap ranges, particularly for high-speed compressor and steam turbine applications where shaft runout compensation is critical.

3300 NSv Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly stocked components within the Bently Nevada 3300 NSv proximity probe ecosystem. Each entry reflects a distinct configuration of probe diameter, cable length, and connector type.

330901-00-90-10-01-05: 3300 NSv 8mm proximity probe, 90cm armored cable, standard connector, -24V DC supply, 200 mV/mil sensitivity, API 670 compliant.

330901-00-90-10-02-05: 3300 NSv 8mm probe, 90cm cable, reverse-mount configuration, extended temperature range (-35°C to +177°C).

330901-00-90-10-01-00: 3300 NSv 8mm probe, 90cm cable, bare-end termination, for field-terminated installations.

330901-00-60-10-01-05: 3300 NSv 8mm probe, 60cm armored cable, standard connector, suitable for compact bearing housing installations.

330901-00-30-10-01-05: 3300 NSv 8mm probe, 30cm cable, short-reach configuration for tight-clearance turbine housings.

330905-00-90-10-01-05: 3300 NSv 5mm proximity probe, 90cm cable, standard connector, 200 mV/mil, for smaller shaft diameter applications.

330905-00-60-10-01-05: 3300 NSv 5mm probe, 60cm cable, standard connector, radial vibration measurement on compressor shafts.

330130-080-01-00: 3300 NSv proximitor sensor, 8mm, -24V DC, 200 mV/mil output, DIN rail mount, for use with 330901 probe series.

330130-080-02-00: 3300 NSv proximitor sensor, 8mm, reverse-polarity output, for legacy rack integration requiring positive voltage output.

330130-050-01-00: 3300 NSv proximitor sensor, 5mm, -24V DC, 200 mV/mil, paired with 330905 probe series.

330180-X1-05: 3300 NSv extension cable, 5-meter, armored, field-wiring between probe and proximitor in high-vibration zones.

330180-X1-10: 3300 NSv extension cable, 10-meter, armored, for installations with remote proximitor mounting.

330180-X1-15: 3300 NSv extension cable, 15-meter, armored, long-run configuration for large turbine pedestals.

330850-02-00: 3300 NSv mounting bracket assembly, 8mm probe, stainless steel, adjustable gap-setting fixture for field installation.

330851-02-00: 3300 NSv mounting bracket assembly, 5mm probe, stainless steel, for compressor and pump shaft monitoring.

330104-00-05: 3300 NSv interconnect cable assembly, probe-to-proximitor, 5-meter, pre-terminated, factory-calibrated matched set.

330104-00-10: 3300 NSv interconnect cable assembly, 10-meter, pre-terminated, factory-calibrated, for remote sensor installations.

Quality Control for the 3300 NSv Range

The 3300 NSv proximity probe system requires functional verification at the system level, not the component level. DriveKNMS applies the following test protocol to all 3300 NSv inventory prior to dispatch:

Gap voltage linearity test: Each probe-proximitor pair is bench-tested across the full linear range (typically 0.25mm to 2.25mm for 8mm probes) using a calibrated target plate of the specified shaft material (AISI 4140 or equivalent). Output voltage is recorded at 0.1mm increments and compared against the factory calibration curve. Deviation exceeding ±1% of full-scale output results in rejection.

Cable continuity and insulation resistance: Extension cables are tested for conductor continuity, shield integrity, and insulation resistance (minimum 100 MΩ at 500V DC) to detect micro-fractures in armored cable assemblies common in high-vibration installations.

Proximitor power supply verification: Proximitor sensors are powered at -24V DC nominal and output voltage is verified at the standard 1.0mm gap reference point. Units outside ±0.5V of the nominal -12V output at reference gap are recalibrated or rejected.
