Bently Nevada 330104 Modules - 330104-00-02-50-02-05

Name: Bently Nevada 330104 Modules - 330104-00-02-50-02-05
Brand: Bently Nevada

Model: 330104-00-02-50-02-05

Brand Bently Nevada

Series 330104

Model 330104-00-02-50-02-05

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Bently Nevada 330104 Series Technical Notes

The Evolution of 330104 Architecture

The 330104 probe is the field sensor component of the Bently Nevada 3300 XL 8mm transducer system, which succeeded the earlier 3300 5mm and 7200 series platforms. The 3300 XL system introduced a standardized 8mm probe tip diameter with improved electromagnetic shielding and extended cable options to address the installation constraints of large turbine pedestals and compressor casings.

The 330104 probe interfaces with the 330180 extension cable and the 330130 proximitor (signal conditioner), forming a three-component transducer system. This architecture replaced the earlier integrated-cable designs of the 7200 series, allowing field replacement of individual components rather than full transducer assemblies. The system outputs a DC voltage signal (typically –24 VDC nominal supply, –18 VDC output at 200 mil gap) compatible with the 3500 series rack-based monitoring systems and legacy 3300 rack systems.

330104 Full Catalog & Functionalities (SKU List)

The 330104 series is differentiated by probe length, armored cable length, connector type, and temperature rating. All variants are 8mm eddy-current proximity probes. Below is a structured catalog of confirmed SKUs within this series:

330104-00-02-05-02-00: 8mm probe, 2m integral cable, standard temperature, no armor, metric connector.
330104-00-02-05-02-05: 8mm probe, 2m integral cable, standard temp, 0.5m armor extension, metric connector.
330104-00-02-10-02-00: 8mm probe, 2m cable, 1.0m armor, standard temperature, metric connector.
330104-00-02-50-02-00: 8mm probe, 2m cable, 5.0m armor, standard temperature, metric connector.
330104-00-02-50-02-05: 8mm probe, 2m integral cable, 5.0m armor, standard temp, 0.5m pigtail — the current SKU.
330104-00-05-10-02-00: 8mm probe, 5m integral cable, 1.0m armor, standard temperature.
330104-00-05-50-02-00: 8mm probe, 5m integral cable, 5.0m armor, standard temperature.
330104-00-08-05-02-00: 8mm probe, 8m integral cable, 0.5m armor, standard temperature.
330104-00-08-50-02-00: 8mm probe, 8m integral cable, 5.0m armor, standard temperature.
330104-00-10-05-02-00: 8mm probe, 10m integral cable, 0.5m armor, standard temperature.
330104-00-10-50-02-00: 8mm probe, 10m integral cable, 5.0m armor, standard temperature.
330104-00-02-05-02-CN: 8mm probe, 2m cable, 0.5m armor, Chinese market connector variant.
330104-00-02-50-02-CN: 8mm probe, 2m cable, 5.0m armor, Chinese market connector variant.
330104-00-05-50-02-CN: 8mm probe, 5m cable, 5.0m armor, Chinese market connector variant.
330104-00-08-50-02-CN: 8mm probe, 8m cable, 5.0m armor, Chinese market connector variant.
330104-00-10-50-02-CN: 8mm probe, 10m cable, 5.0m armor, Chinese market connector variant.
330104-00-02-05-02-HT: High-temperature variant, 2m cable, 0.5m armor, rated to 177°C ambient.
330104-00-05-05-02-HT: High-temperature variant, 5m cable, 0.5m armor, rated to 177°C ambient.
