Bently Nevada 330180 Series Modules - 330180-X2-00 MOD:181634-27

Technical Dossier

Product Details And Specifications

Bently Nevada 330180 Series Technical Notes

The Bently Nevada 330180 Series represents one of the most widely deployed proximity transducer system components in global heavy industry. Engineered to interface with the 3300 XL and legacy 3300 Series monitoring systems, the 330180 extension cable assemblies and proximity sensors are installed across petrochemical refineries, nuclear power stations, offshore platforms, and large-scale rotating machinery facilities. Their role is critical: they form the physical signal path between the eddy-current probe tip and the Proximitor sensor, directly affecting the accuracy of shaft vibration, axial position, and speed measurements that protect turbines, compressors, and pumps from catastrophic failure. The 330180 Series is manufactured to API 670 standards and remains a reference component in machinery protection system (MPS) specifications globally.

330180 Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly sourced models within the Bently Nevada 330180 extension cable and proximity transducer series. Each entry reflects a distinct configuration defined by cable length, connector specification, or environmental rating.

330180-X2-00 MOD:181634-27: 3300 XL 8mm extension cable, standard configuration, field-verified MOD code.
330180-51-00: 5-meter extension cable, standard temperature, straight connectors, 3300/3500 compatible.
330180-51-05: 5-meter extension cable, high-temperature variant, rated to +177°C continuous.
330180-90-00: 9-meter extension cable, standard temperature, used in large turbine pedestals.
330180-90-05: 9-meter extension cable, high-temperature, nuclear and refinery service.
330180-51-00-CN: 5-meter cable, China-market configuration, CE-marked, standard connectors.
330180-90-00-CN: 9-meter cable, China-market configuration, CE-marked.
330180-51-00-HT: 5-meter, extended high-temperature rating, armored jacket option.
330180-25-00: 2.5-meter short-run extension, used in compact bearing housings.
330180-25-05: 2.5-meter, high-temperature, compact installation variant.
330180-51-00-EX: ATEX/IECEx certified, 5-meter, Zone 1 hazardous area rated.
330180-90-00-EX: ATEX/IECEx certified, 9-meter, Zone 1 hazardous area rated.
330180-51-00-SS: Stainless steel armored jacket, 5-meter, offshore/marine service.
330180-90-00-SS: Stainless steel armored jacket, 9-meter, offshore/marine service.
330180-51-00-CSA: CSA-certified variant, 5-meter, North American hazardous location compliance.
330180-90-00-CSA: CSA-certified variant, 9-meter, North American hazardous location compliance.
330180-51-05-EX: High-temperature + ATEX dual-rated, 5-meter, refinery critical service.
