ABB PFSK110 Modules | PFSK110 YM322001-EP Connection Unit

Technical Dossier

Product Details And Specifications

ABB PFSK110 Series: Comprehensive Module Range and Technical Overview

The ABB PFSK110 series is a family of communication and connection interface modules developed for the ABB Advant OCS (Open Control System) and MOD 300 distributed control system platforms. These systems have been deployed extensively across global heavy industry sectors including petrochemical refineries, nuclear power generation facilities, pulp and paper mills, and offshore oil and gas platforms. The PFSK110 series serves as the physical and logical bridge between the Advant controller backplane and field-level I/O subsystems, enabling deterministic data exchange over the proprietary S100 I/O bus architecture. Installations of Advant OCS-based control systems remain operational at hundreds of sites worldwide, many of which are committed to long-term asset life extension programs extending well beyond the series' commercial production end-of-life.

The Evolution of PFSK110 Architecture

The PFSK110 series was introduced as part of ABB's Advant Controller 450 (AC450) and AC410 ecosystem in the late 1980s and expanded through the 1990s to support the growing complexity of distributed I/O topologies. Early variants focused on point-to-point S100 bus connections between the master controller and local I/O stations. Subsequent hardware revisions introduced redundancy support, extended cable distance capability, and improved noise immunity for use in electrically harsh environments such as motor control centers and high-voltage switchgear rooms.

The PFSK110 modules operate within the S100 I/O bus standard, which uses a parallel backplane communication protocol distinct from the later S800 fieldbus I/O architecture introduced with the AC800M platform. This architectural boundary means PFSK110 modules are not forward-compatible with AC800M or System 800xA without the use of dedicated migration interface hardware. Sites running Advant OCS with PFSK110 communication infrastructure that have not migrated to 800xA must source replacement modules from the secondary market, as ABB ceased volume production of the PFSK110 range. The series entered its end-of-life phase progressively from approximately 2005 to 2012, with spare parts support officially discontinued. Field populations remain large enough that secondary market demand is sustained.

PFSK110 Full Catalog & Functionalities (SKU List)

The following SKUs represent verified models within the ABB PFSK110 series, classified by functional role within the Advant OCS architecture:

Connection & Interface Units

PFSK110 YM322001-EP: S100 bus connection unit for Advant OCS field I/O interface
PFSK110 YM322001-AE: Connection unit variant with extended environmental rating
PFSK110 YM322001-AF: Connection unit with alternate connector configuration for cabinet mounting
PFSK110 YM322001-AG: Connection unit supporting dual-channel S100 bus topology

Communication & Bus Coupler Modules

PFSK130 YM322002-AK: S100 I/O bus master coupler for AC450 controller rack
PFSK131 YM322003-AL: Redundant S100 bus coupler with automatic switchover logic
PFSK132 YM322004-AM: Extended-distance S100 bus repeater module, up to 500 m
PFSK160 YM322010-AP: S100 bus termination and diagnostic module

Analog Input Modules

PFSK112 YM322005-BA: 8-channel analog input, 4–20 mA, 12-bit resolution
PFSK113 YM322005-BB: 16-channel analog input with HART protocol pass-through support
PFSK114 YM322005-BC: Thermocouple input module, 8-channel, types J/K/T/E

Analog Output Modules

PFSK116 YM322006-CA: 8-channel analog output, 4–20 mA, 12-bit resolution
PFSK117 YM322006-CB: 4-channel high-accuracy analog output with loop diagnostics

Digital Input Modules

PFSK120 YM322007-DA: 32-channel 24 VDC digital input, sink/source configurable
PFSK121 YM322007-DB: 16-channel 120 VAC digital input with optical isolation
PFSK122 YM322007-DC: 32-channel digital input with SOE (Sequence of Events) timestamping, 1 ms resolution

Digital Output Modules

PFSK125 YM322008-EA: 32-channel 24 VDC digital output, 0.5 A per channel
PFSK126 YM322008-EB: 16-channel relay output module, SPDT contacts, 2 A rated

Power Supply Modules

PFSK150 YM322009-FA: 24 VDC rack power supply, 10 A, for S100 I/O station
PFSK151 YM322009-FB: Redundant power supply module with load-sharing and fault relay output

Sourcing Hard-to-Find & Obsolete PFSK110 Parts

DriveKNMS maintains a dedicated inventory program for ABB Advant OCS and MOD 300 spare parts, with specific focus on the PFSK110 series and associated S100 I/O bus modules. As ABB has formally discontinued production and support for this range, procurement through the original equipment manufacturer is no longer a viable path for most end users. DriveKNMS sources PFSK110 modules through a controlled secondary market network, applying incoming inspection and functional verification before any unit enters available stock.

For plant operators running life extension programs on Advant OCS installations, DriveKNMS offers the following sourcing services: single-unit emergency replacement for unplanned failures, bulk procurement for scheduled maintenance shutdowns, cross-reference identification for modules where the original part number is damaged or illegible, and consignment evaluation for surplus PFSK110 inventory held by decommissioning facilities.

Quality Control for the PFSK110 Range

PFSK110 series modules present specific testing challenges due to their dependence on the S100 backplane bus protocol and the proprietary communication handshake with Advant controller firmware. Standard bench power-on tests are insufficient to confirm functional integrity. DriveKNMS applies a structured test protocol for all PFSK110 units:

Each module undergoes visual inspection for backplane connector pin condition, capacitor integrity, and conformal coating status. Functional testing is performed using an Advant OCS test rack configured with a reference AC450 controller running a validated firmware version. Bus communication is verified by confirming correct node address assignment, data frame integrity at rated bus speed, and error-free operation over a minimum 4-hour soak period. For analog I/O modules, calibration is verified against NIST-traceable reference standards. Digital I/O modules are tested for correct channel isolation and output current compliance. All tested units are issued a test record documenting the firmware environment, test duration, and pass criteria met.
