Honeywell CC-TAIX61 51307077-175: Experion PKS C300 Analog Input Module

Name: Honeywell CC-TAIX61 51307077-175: Experion PKS C300 Analog Input Module
Brand: Honeywell

Model: CC-TAIX61 51307077-175

Brand Honeywell

Series Pending

Model CC-TAIX61 51307077-175

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Honeywell Experion PKS C300 Series Technical Notes

The Honeywell Experion PKS C300 controller platform is one of the most widely deployed Distributed Control Systems (DCS) in global heavy industry. Installed across petrochemical complexes, nuclear power stations, oil refineries, pulp and paper mills, and LNG terminals, the C300 architecture represents Honeywell's primary process automation backbone for large-scale continuous operations. The CC-TAIX61 (P/N 51307077-175) is a 16-channel Analog Input HART module within this ecosystem, designed for direct integration into the Series C I/O subsystem via the FIM (Field Interface Module) backplane.

The Evolution of Experion PKS C300 Architecture

Honeywell introduced the Experion PKS platform in 2001 as a successor to the TDC 3000 and PlantScape systems. The C300 controller, released as the core processing unit of this platform, replaced the earlier C200 and C200E controllers while maintaining backward compatibility with legacy Series C I/O hardware. The C300 communicates over the FTE (Fault Tolerant Ethernet) network, a dual-ring 100 Mbps redundant backbone that replaced the older UCN (Universal Control Network) used in TDC 3000 installations.

The Series C I/O modules — identified by the CC-T prefix — were designed to interface with the C300 via the CIOM-A (Control I/O Module Adapter) and FIM4/FIM8 backplane assemblies. Early revisions of these modules (pre-2008) used a single-bus backplane architecture; later revisions introduced dual-bus redundancy for critical process loops. The CC-TAIX61 belongs to the mature generation of this I/O family, supporting HART pass-through communication for field device diagnostics — a capability absent in earlier CC-AI01 and CC-AI02 analog input variants.

Experion PKS C300 Full Catalog & Functionalities (SKU List)

Analog Input Modules

CC-TAIX61 / 51307077-175: 16-channel Analog Input, HART-enabled, 4–20 mA, Series C I/O
CC-TAIX01 / 51304362-175: 8-channel Analog Input, non-HART, 4–20 mA, Series C I/O
CC-TAIX11 / 51304362-275: 8-channel Analog Input, HART, 4–20 mA, Series C I/O
CC-TAIX51 / 51307076-175: 16-channel Analog Input, non-HART, 4–20 mA, Series C I/O

Analog Output Modules

CC-TAOX11 / 51304453-175: 8-channel Analog Output, HART, 4–20 mA, Series C I/O
CC-TAOX51 / 51307080-175: 16-channel Analog Output, non-HART, 4–20 mA, Series C I/O
CC-TAOX61 / 51307080-275: 16-channel Analog Output, HART-enabled, 4–20 mA, Series C I/O

Digital Input Modules

CC-TDIL01 / 51304516-175: 32-channel Digital Input, 24 VDC, Series C I/O
CC-TDIL11 / 51304516-275: 32-channel Digital Input, 120 VAC, Series C I/O
CC-TDIL51 / 51307082-175: 64-channel Digital Input, 24 VDC, high-density, Series C I/O

Digital Output Modules

CC-TDOB01 / 51304453-275: 32-channel Digital Output, 24 VDC, relay-isolated, Series C I/O
CC-TDOB11 / 51304453-375: 32-channel Digital Output, 120 VAC, relay-isolated, Series C I/O
CC-TDOB51 / 51307083-175: 64-channel Digital Output, 24 VDC, high-density, Series C I/O

Controller & Communication Modules

CC-PCF901 / 51454352-175: C300 Process Controller Module, primary CPU, FTE-connected
CC-PCF902 / 51454352-275: C300 Process Controller Module, redundant pair unit
CC-FIM4 / 51304441-175: Field Interface Module, 4-slot I/O backplane, CIOM-A bus
CC-FIM8 / 51304441-275: Field Interface Module, 8-slot I/O backplane, CIOM-A bus
CC-PWRR01 / 51304443-175: Redundant Power Supply Module, 24 VDC, Series C chassis

Quality Control for the Experion PKS C300 Range

C300 Series C I/O modules present specific test challenges due to their CIOM-A backplane bus protocol and HART communication stack. DriveKNMS applies the following verification procedures to all C300 I/O modules prior to shipment:

Backplane bus continuity test: verifies all CIOM-A edge connector pins against Honeywell's published pinout specification for FIM4/FIM8 chassis.
HART communication validation: for HART-enabled modules (CC-TAIX61, CC-TAIX11, CC-TAOX11, CC-TAOX61), each channel is tested for HART token-passing response using a calibrated HART master device.
Analog channel calibration check: all AI/AO channels are verified at 4 mA, 12 mA, and 20 mA reference points against a traceable current source/sink.
Firmware revision identification: module firmware version is read and documented; customers are notified of any revision mismatch relative to their system's minimum compatible version.
Visual and mechanical inspection: PCB, backplane connector, and housing are inspected for corrosion, pin damage, and capacitor condition.
