Mitsubishi MELSEC-Q Series Network Modules: QJ71LP21S-25

Model: QJ71LP21S-25

Brand Mitsubishi Electric

Series MELSEC-Q

Model QJ71LP21S-25

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Mitsubishi Electric MELSEC-Q Series: Comprehensive Module Range and Technical Overview

The Mitsubishi Electric MELSEC-Q Series is a modular programmable logic controller (PLC) platform deployed across global heavy industry sectors including petrochemical refineries, nuclear power generation facilities, steel manufacturing plants, and offshore oil & gas installations. Its multi-CPU architecture, high-speed backplane bus (up to 400 Mbps), and deterministic scan-cycle performance have made it the reference platform for process-critical automation in facilities requiring IEC 61511 functional safety compliance. The QJ71LP21S-25 is a MELSEC-Q optical loop network module supporting MELSECNET/H optical loop topology at 25 Mbps, used for peer-to-peer inter-PLC communication in distributed control architectures.

The Evolution of MELSEC-Q Series Architecture

The MELSEC-Q platform was introduced in the late 1990s as the successor to the MELSEC-A and MELSEC-QnA series, consolidating Mitsubishi Electric's industrial PLC lineup into a unified high-performance backplane architecture. Early Q-series systems used the QnA-compatible CPU modules (Q02, Q02H) with a 32-bit RISC processor and a dedicated system bus operating at 50 Mbps. The introduction of the Universal model CPUs (Q03UD, Q04UD, Q06UD, Q13UD, Q26UD) in the mid-2000s expanded memory capacity, added built-in Ethernet ports, and increased the internal bus speed to 400 Mbps, enabling tighter multi-CPU synchronization. Network communication evolved in parallel: MELSECNET/10 coaxial loop was superseded by MELSECNET/H optical and coaxial variants, which in turn were complemented by CC-Link IE Field and CC-Link IE Control for Gigabit-class deterministic networking. As of 2024, Mitsubishi Electric has announced the end-of-sale transition for several Q-series CPU and network modules, with the iQ-R Series (R-series) designated as the long-term replacement platform. Installed Q-series bases remain in service under extended lifecycle support agreements, making spare parts availability a critical operational requirement for asset-intensive industries.

MELSEC-Q Full Catalog & Functionalities (SKU List)

CPU Modules

Q02UCPU: Universal model CPU, 20K steps, 256KB memory, built-in USB port.
Q03UDECPU: Universal model CPU, 30K steps, built-in Ethernet, SD card slot.
Q06UDEHCPU: Universal model CPU, 60K steps, dual built-in Ethernet, high-speed processing.
Q13UDEHCPU: Universal model CPU, 130K steps, extended I/O and network capacity.
Q26UDEHCPU: Universal model CPU, 260K steps, maximum program capacity in Q-series.

Network Communication Modules

QJ71LP21S-25: MELSECNET/H optical loop master/local, 25 Mbps, ST-type fiber connector.
QJ71LP21-25: MELSECNET/H optical loop, 25 Mbps, standard fiber, predecessor to S-25 variant.
QJ71LP21G: MELSECNET/H optical loop, 10 Mbps, GI fiber, legacy coexistence support.
QJ71BR11: MELSECNET/H coaxial bus master/local module, 10 Mbps.
QJ71E71-100: Ethernet interface module, 100BASE-TX, MELSOFT/SLMP protocol support.
QJ71GF11-T2: CC-Link IE Field master/local module, 1 Gbps, twisted-pair.
QJ61BT11N: CC-Link V2 master/local module, up to 10 Mbps, 64-station support.
QJ71C24N: Serial communication module, RS-232/RS-422/RS-485, 2-channel.

Digital I/O Modules

QX40: 16-point DC input module, 24VDC, sink/source compatible.
QX81: 32-point DC input module, 24VDC, high-density terminal block.
QY10: 16-point transistor output module, 12–24VDC, 0.5A per point.
QY80: 32-point transistor output module, 24VDC, high-density, source type.

Analog I/O Modules

Q64AD: 4-channel analog input, 16-bit resolution, voltage/current selectable.
Q68DAIN: 8-channel analog input, 16-bit, high-speed sampling, isolated channels.

Power Supply Modules

Q61P: 100–240VAC input power supply, 6A output, for Q-series main base.
Q62P: 100–240VAC input power supply, 6A, redundant-capable configuration.

Sourcing Hard-to-Find & Obsolete MELSEC-Q Parts

Quality Control for the MELSEC-Q Range

MELSEC-Q network modules such as the QJ71LP21S-25 incorporate a proprietary optical transceiver and MELSECNET/H ASIC that require protocol-level validation beyond standard power-on testing. DriveKNMS applies the following test procedures to all Q-series network modules prior to dispatch: optical power output measurement on ST-type fiber ports (reference: Mitsubishi Electric specification ±3 dBm tolerance); MELSECNET/H loop initialization and token-passing verification using a dedicated Q-series test rack; backplane bus communication integrity check at 400 Mbps using a Q06UDEHCPU reference CPU; firmware version identification and comparison against Mitsubishi Electric's published version matrix; and 48-hour burn-in cycle under operational load conditions. All test results are documented and supplied with each unit shipment.
