Schneider Electric Modicon Quantum 140 Modules — 140DAI75300

Technical Dossier

Product Details And Specifications

Schneider Electric Modicon Quantum 140 Series Technical Notes

The Modicon Quantum 140 series is Schneider Electric's flagship large-scale PLC platform, engineered for mission-critical process control in heavy industry. Deployed across petrochemical complexes, nuclear power generation facilities, offshore oil & gas platforms, and continuous-process refineries, the Quantum 140 architecture supports hot-standby redundancy, distributed I/O over Modbus Plus and Ethernet, and deterministic scan cycles required by IEC 61511 SIL-rated safety loops. Its 19-inch rack-mount backplane accepts up to 16 modules per local rack, with remote I/O drops extending to thousands of points across a single control network. The platform's longevity — spanning from its 1990s introduction through active installed-base maintenance today — makes it one of the most widely supported legacy DCS/PLC systems in global industrial automation.

The Evolution of Modicon Quantum 140 Architecture

The Quantum 140 platform was introduced by Modicon (subsequently acquired by Schneider Electric in 1994) as a successor to the Modicon 984 series. The original architecture centered on the 140CPU11302 and 140CPU21304 processors, which communicated exclusively over Modbus Plus (MB+). By the late 1990s, Schneider introduced Ethernet-capable CPUs (140CPU65150, 140CPU65160) supporting Modbus TCP/IP, enabling integration with SCADA systems and plant historians without protocol converters.

The I/O subsystem evolved in parallel: early discrete modules operated at 24 VDC with 16-point density; later generations introduced 32-point high-density modules and analog modules with HART pass-through capability. The 140CRP93200 RIO head adapter and 140CRA93200 remote adapter enabled distributed architectures across fiber and copper Modbus Plus drops. Hot-standby CPU pairs (140CPU67160) and the Unity Pro programming environment (replacing Concept/ProWORX) represent the platform's mature phase. As of 2026, the Quantum 140 series is in the End of Commercialization / Long-Term Maintenance phase; Schneider Electric continues to supply spare parts and firmware patches under its Green Premium lifecycle program, but no new feature development is planned.

Modicon Quantum 140 Full Catalog & Functionalities (SKU List)

Discrete Input Modules (DI)

• 140DAI75300: 32-point 24 VDC discrete input module, sink/source, current-sinking, IEC Type 1 — the subject SKU of this listing.
• 140DAI54000: 16-point 115 VAC discrete input module, isolated, for high-voltage field devices.
• 140DAI74000: 32-point 24 VDC discrete input, non-isolated, standard density for general-purpose I/O racks.
• 140DDI35300: 32-point 24 VDC discrete input, high-speed, for pulse counting and encoder feedback applications.

Discrete Output Modules (DO)

• 140DAO84000: 16-point 115/230 VAC discrete output, relay contact, 2 A per point, for motor starter and valve actuator control.
• 140DDO35300: 32-point 24 VDC discrete output, transistor sink, 0.5 A per point, high-density digital output.
• 140DAO85300: 32-point 115 VAC discrete output, triac, zero-crossing switching for resistive loads.

Analog Input Modules (AI)

• 140ACI04000: 8-channel analog current input, 4–20 mA, 12-bit resolution, for process transmitter loops.
• 140AVI03000: 8-channel analog voltage input, ±10 V / 0–10 V selectable, 12-bit, for position and speed feedback.
• 140ARI03010: 8-channel RTD/resistance input module, supports PT100, PT1000, Ni100, for temperature measurement.
• 140ATI03000: 8-channel thermocouple input, types J/K/T/E/R/S/B, cold-junction compensated, 14-bit resolution.

Analog Output Modules (AO)

• 140ACO02000: 4-channel analog current output, 4–20 mA, 12-bit, for control valve positioners and variable-speed drives.
• 140AVO02000: 4-channel analog voltage output, 0–10 V / ±10 V, 12-bit, for proportional valve and actuator control.

CPU / Processor Modules

• 140CPU65150: Quantum CPU with Modbus Plus + 10 Mbps Ethernet, 512 KB user memory, Unity Pro compatible.
• 140CPU67160: Hot-standby capable CPU, dual Ethernet ports, 1 MB user memory, for redundant control architectures.
• 140CPU11302: Entry-level Quantum CPU, Modbus Plus only, 64 KB memory — first-generation processor, now obsolete.

Communication & Network Modules

• 140NOE77100: Ethernet TCP/IP network option module, 10/100 Mbps, supports Modbus TCP and FTP for data logging.
• 140CRP93200: RIO head adapter for Modbus Plus remote I/O drops, supports up to 31 remote drops per network.
• 140CRA93200: Remote I/O adapter module, installed in remote racks, pairs with 140CRP93200 head adapter.

Power Supply Modules

• 140CPS11420: 24 VDC rack power supply, 8 A output, for standard Quantum local and remote racks.
• 140CPS21400: 115/230 VAC rack power supply, 8 A, universal input voltage, for AC-powered panel installations.

Quality Control for the Modicon Quantum 140 Range

Quantum 140 modules present specific test challenges due to their backplane bus architecture and multi-drop Modbus Plus communication protocol. DriveKNMS applies the following verification procedures to all Quantum 140 units processed through its facility:

• Backplane continuity test: Each module's edge connector is inspected under 10× magnification and tested for pin continuity against Schneider's published backplane pinout specifications.
• Power-on functional test: Modules are seated in a live Quantum test rack running Unity Pro v13.1. CPU modules execute a diagnostic ladder program; I/O modules are exercised through all channels using calibrated signal sources and loads.
• Modbus Plus network test: Communication modules and CPU units are verified for MB+ token-passing behavior using a Modicon SA85 network analyzer card.
• Analog calibration: All analog input and output modules are calibrated against a Fluke 726 precision multifunction calibrator. Calibration certificates are issued on request.
• Firmware version documentation: CPU and communication module firmware versions are recorded and disclosed in the shipment documentation to ensure compatibility with the customer's existing Unity Pro or Concept project files.
