Siemens SIMATIC SMART IE V3 Modules: 6AV7872-1CE54-0AF0

Technical Dossier

Product Details And Specifications

Siemens SIMATIC SMART IE V3 Series Technical Notes

The Evolution of SIMATIC SMART IE Architecture

The SIMATIC SMART IE product line evolved from Siemens' earlier SIMATIC Panel PC 670/870 platforms introduced in the early 2000s. The transition to the SMART IE designation marked a shift toward embedded Windows CE and Windows XP Embedded operating systems, followed by Windows 7 Embedded Standard in later revisions. The V3 generation introduced enhanced backplane bus communication, improved EMC shielding, and support for PROFINET IO alongside legacy PROFIBUS DP interfaces.

Key architectural milestones by generation:

SMART IE V1: Celeron M processors, 512 MB RAM ceiling, Windows CE / WinXP Embedded, single Ethernet port, PROFIBUS DP only.
SMART IE V2: Core 2 Duo support, expanded to 2 GB RAM, dual serial interfaces, early PROFINET readiness.
SMART IE V3: Intel Core i5/i7 processors, up to 8 GB DDR3 RAM, dual Gigabit Ethernet, CFast storage, PROFINET IO integrated, DVI-I output, USB 3.0. This is the current reference generation.

Compatibility between generations is limited at the backplane and OS driver level. V1/V2 software images are not directly portable to V3 hardware without re-engineering. Plants operating mixed-generation fleets must maintain separate spare pools. The SMART IE V3 series has entered the mature/end-of-mainstream-support phase; Siemens has transitioned new project recommendations to the SIMATIC IPC477E and IPC677E lines. The installed base of SMART IE V3 units in active plants remains substantial, and DriveKNMS provides dedicated lifecycle extension support for all models in this series.

SIMATIC SMART IE V3 Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly deployed models within the SIMATIC SMART IE V3 product family, organized by processor tier and display size:

6AV7872-1AA10-0AC0: 15" TFT, Celeron, 1 GB RAM, WinXP Embedded, single Ethernet, entry-level HMI visualization node.
6AV7872-1AA20-0AC0: 15" TFT, Celeron, 2 GB RAM, Windows CE 6.0, compact low-power field visualization node.
6AV7872-1AB10-0AC0: 15" TFT, Celeron, 2 GB RAM, WinXP Embedded, dual serial ports, PROFIBUS DP ready.
6AV7872-1BA10-0AC0: 15" TFT, Core 2 Duo, 2 GB RAM, Win7 Embedded, dual Ethernet, enhanced graphics subsystem.
6AV7872-1BA20-0AC0: 15" TFT, Core 2 Duo, 2 GB RAM, Win7 Embedded, PROFIBUS DP + Ethernet, legacy DCS integration.
6AV7872-1BD10-0AC0: 15" TFT, Core 2 Duo, 4 GB RAM, Win7 Embedded, RAID-capable, extended temperature range.
6AV7872-1BD20-0AC0: 15" TFT, Core 2 Duo, 4 GB RAM, Win7 Embedded, SSD, vibration-resistant field cabinet mount.
6AV7872-1CE10-0AF0: 15" TFT, Core i5, 2 GB RAM, Win7 Embedded Standard, single Gigabit Ethernet, standard panel-mount.
6AV7872-1CE20-0AF0: 15" TFT, Core i5, 4 GB RAM, Win7 Embedded, dual Ethernet, CFast storage slot.
6AV7872-1CE30-0AF0: 15" TFT, Core i5, 4 GB RAM, Win7 Embedded, PROFINET IO integrated, DVI-I output.
6AV7872-1CE44-0AF0: 15" TFT, Core i5, 4 GB RAM, Win7 Embedded, USB 3.0, extended storage configuration.
6AV7872-1CE54-0AF0: 15" TFT, Core i5, 4 GB RAM, Win7 Embedded, PROFINET/IE, full I/O complement, panel-mount — primary reference SKU.
6AV7872-1DE10-0AF0: 19" TFT widescreen, Core i5, 4 GB RAM, Win7 Embedded, dual Gigabit Ethernet, rack-mount option.
6AV7872-1DE20-0AF0: 19" TFT, Core i5, 8 GB RAM, Win7 Embedded, RAID 1 SSD, high-availability configuration.
6AV7872-1EE10-0AF0: 19" TFT, Core i7, 8 GB RAM, Win7 Embedded, dual Ethernet, maximum processing tier.
6AV7872-1EE20-0AF0: 19" TFT, Core i7, 8 GB RAM, Win10 IoT Enterprise, CFast + HDD dual storage, latest OS revision.

Quality Control for the SIMATIC SMART IE V3 Range

SIMATIC SMART IE V3 units present specific QC challenges due to their integrated backplane bus architecture and multi-layer PCB construction. DriveKNMS applies the following test protocol to all units processed through its facility:
