Triconex Tricon DO 3401S2 Digital Output Module

Name: Triconex Tricon DO 3401S2 Digital Output Module
Brand: Triconex

Model: DO 3401S2

Brand Triconex

Series Tricon

Model DO 3401S2

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Triconex Tricon Series Technical Notes

The Evolution of Tricon Architecture

The Triconex Tricon platform was introduced in the late 1980s as one of the first commercially available TMR safety controllers. Early hardware generations (Tricon v1–v7) used proprietary backplane bus technology with dedicated I/O chassis and fixed-slot addressing. The transition to Tricon v9 and v10 introduced enhanced communication modules (TCM), expanded I/O density, and compatibility with TriStation 1131 programming software. The v10 generation added Ethernet-based peer-to-peer communication and support for HART pass-through on analog modules.

Compatibility between generations is constrained by chassis type and main processor revision. Modules from the v7 era are generally not hot-swappable into v10 chassis without firmware alignment. As of 2024, Triconex (a Schneider Electric brand) has transitioned its primary development focus to the Tricon CX platform, positioning the legacy Tricon v9/v10 hardware in a long-term support (LTS) lifecycle. This makes sourcing of spare modules such as the DO 3401S2 a critical operational requirement for sites with 10–20 year maintenance horizons.

Tricon Full Catalog & Functionalities (SKU List)

Digital Output Modules

DO 3401S2: 32-channel 24 VDC digital output, SIL 3, TMR, solid-state outputs, 0.5 A per channel
DO 3401: 32-channel 24 VDC digital output module, earlier revision of the S2 variant
DO 3601: 16-channel 120 VAC digital output module for high-voltage actuator interfaces
DO 3603: 16-channel 24 VDC digital output, relay-isolated, for solenoid valve applications

Digital Input Modules

DI 3501: 32-channel 24 VDC digital input module, field-powered, TMR voting
DI 3501S: 32-channel 24 VDC digital input, enhanced diagnostics revision
DI 3503: 32-channel 120 VAC digital input module for high-voltage field devices
DI 3601: 16-channel 24 VDC digital input, isolated, for critical sensor interfaces

Analog Input Modules

AI 3351: 8-channel 4–20 mA analog input module with HART support
AI 3353: 8-channel thermocouple/RTD analog input module
AI 3703: 16-channel 4–20 mA analog input, high-density configuration

Analog Output Modules

AO 3481: 8-channel 4–20 mA analog output module, SIL 2 rated

Communication & Network Modules

TCM 4351: Tricon Communication Module, Ethernet/IP and Modbus TCP gateway
TCM 4352: Enhanced communication module with redundant Ethernet ports
NCM 4310: Network Communication Module for peer-to-peer Tricon linking

Main Processors & Power

MP 3008: Main Processor module, v9/v10 compatible, 32-bit TMR CPU
PS 3100: 24 VDC power supply module for Tricon chassis
PS 3101: Redundant power supply module, hot-swap capable

Quality Control for the Tricon Range

Tricon modules incorporate complex TMR backplane bus interfaces and proprietary diagnostic firmware. Standard bench testing is insufficient to validate module integrity. DriveKNMS applies a multi-stage verification protocol specific to the Tricon platform:

Visual inspection per IPC-A-610 Class 3 criteria, including backplane connector pin inspection and conformal coating integrity check
Powered functional test using a Tricon chassis test rig with TriStation 1131 diagnostic software to verify all I/O channels, TMR voting logic, and LED status indicators
For the DO 3401S2: individual channel load test at rated current (0.5 A per channel), short-circuit protection verification, and output leakage current measurement
Firmware revision identification and documentation to confirm compatibility with target system version
Final burn-in cycle (minimum 24 hours) under simulated field load conditions
