YOKOGAWA FA-M3 F3RZ81-ON Communication Module

Name: YOKOGAWA FA-M3 F3RZ81-ON Communication Module
Brand: Yokogawa

Model: F3RZ81-ON

Brand Yokogawa

Series FA-M3 F3RZ81-ON

Model F3RZ81-ON

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

YOKOGAWA FA-M3 Series Technical Notes

The YOKOGAWA FA-M3 (also marketed under the STARDOM platform for process-oriented applications) is a modular programmable controller system with a documented installation base across global heavy industry sectors including petrochemical complexes, nuclear auxiliary systems, offshore platforms, and continuous-process refineries. The FA-M3 architecture is characterized by a high-speed backplane bus, deterministic scan cycle performance, and a broad I/O module library that supports both discrete and analog signal types. Its multi-CPU configuration capability and redundancy options have made it a standard reference design in safety-instrumented and high-availability control loops. The F3RZ81-ON specifically functions as a communication interface module within this ecosystem, enabling protocol-level integration between the FA-M3 rack and external networks or host systems.

The Evolution of FA-M3 Architecture

The FA-M3 platform was introduced by YOKOGAWA in the mid-1990s as a successor to earlier YEWMAC and FA500 controller families. The initial hardware generation used a parallel backplane with proprietary inter-module communication. Subsequent revisions introduced the F3-series module designation, standardizing the physical form factor and electrical interface across CPU, I/O, and communication module types.

The F3SP-series CPU modules (e.g., F3SP28-3N, F3SP38-6N, F3SP58-6H, F3SP67-6S) represent successive generations of processing capability, with later variants supporting IEC 61131-3 structured text and function block programming in addition to ladder logic. Communication architecture evolved from point-to-point RS-232/RS-422 links (F3LC01, F3LC11) through Ethernet TCP/IP modules (F3LE01-5T, F3LE12-5T) and fieldbus adapters (PROFIBUS-DP via F3LP01-0N, DeviceNet via F3LD01-0N). The F3RZ-series modules address specific remote I/O and network extension requirements within this lineage. Compatibility constraints exist between early-generation base units (F3BU04-0N, F3BU06-0N) and later high-density I/O modules; slot assignment rules and power budget calculations must be verified against the FA-M3 system configuration manual (IM 34M06C11-01E) before substitution.

FA-M3 Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly stocked modules within the YOKOGAWA FA-M3 product family. Modules are grouped by functional category.

CPU Modules

F3SP28-3N: Sequence CPU, 14K steps, RS-232C port, basic ladder support.
F3SP38-6N: Sequence CPU, 30K steps, dual RS-232C, expanded I/O capacity.
F3SP58-6H: High-speed CPU, 60K steps, Ethernet-ready, IEC 61131-3 support.
F3SP67-6S: High-performance CPU, 120K steps, multi-task execution, SFC support.
F3SP76-7S: Advanced CPU, 250K steps, redundancy-compatible, high-speed scan.

Communication Modules

F3RZ81-ON: Remote I/O master/slave communication module; enables distributed rack extension over dedicated FA-M3 network link.
F3LC01-1F: Serial communication module, RS-232C, point-to-point protocol support.
F3LC11-1F: Serial communication module, RS-422/RS-485, multi-drop capable.
F3LE01-5T: Ethernet communication module, 10BASE-T, Modbus TCP and proprietary protocol.
F3LE12-5T: Ethernet communication module, 100BASE-TX, enhanced throughput for SCADA integration.
F3LP01-0N: PROFIBUS-DP master module, supports up to 125 slave nodes.
F3LD01-0N: DeviceNet master/slave module, CIP-compliant messaging.

Analog I/O Modules

F3AD04-1N: 4-channel analog input, 4–20 mA / 1–5 V, 12-bit resolution.
F3AD08-4N: 8-channel analog input, multi-range, 16-bit resolution.
F3DA04-1N: 4-channel analog output, 4–20 mA / 1–5 V, 12-bit resolution.

Digital I/O Modules

F3XD32-3F: 32-channel DC digital input, 24 VDC, sink/source compatible.
F3YD32-3F: 32-channel DC digital output, 24 VDC, transistor output, 0.1 A per point.
F3XD16-3N: 16-channel DC digital input, isolated, high-noise-immunity design.

Power Supply Modules

F3PU20-0S: Power supply module, 100–240 VAC input, 5 VDC / 4 A output, for standard base units.
F3PU10-0S: Power supply module, 24 VDC input, compact form factor for panel-mount applications.

Quality Control for the FA-M3 Range

FA-M3 communication modules including the F3RZ81-ON present specific verification challenges due to their backplane-dependent initialization sequence and network-layer handshake requirements. DriveKNMS applies a structured test protocol for this module category:
