Honeywell C300 Series Modules: CC-PCNT02 51454551-275

Name: Honeywell C300 Series Modules: CC-PCNT02 51454551-275
Brand: Honeywell

Model: CC-PCNT02 51454551-275

Brand Honeywell

Series C300 Series

Model CC-PCNT02 51454551-275

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Honeywell C300 Series Technical Notes

The Honeywell C300 Controller Series is a core component of the Experion PKS (Process Knowledge System) distributed control system platform, deployed across global heavy industry including petrochemical refineries, nuclear power stations, LNG terminals, pulp and paper mills, and pharmaceutical manufacturing facilities. The C300 architecture succeeded the legacy TDC 3000 and PlantScape platforms and remains one of the most widely installed DCS controller families in continuous process industries. Its modular backplane design, redundancy support, and FOUNDATION Fieldbus / HART integration make it a reference standard for process automation engineers worldwide. The CC-PCNT02 51454551-275 is a redundant-capable pulse count input module within this ecosystem, used for high-speed counter and frequency measurement in flow metering and rotating equipment monitoring.

The Evolution of C300 Architecture

The C300 series was introduced by Honeywell as part of the Experion PKS R100 release in the early 2000s, succeeding the TDC 3000 LCN/UCN architecture and the PlantScape platform. Early C300 deployments used the Series C I/O subsystem with CIOM-A backplanes and CC-IP01 / CC-IP02 interface modules for I/O link communication. Subsequent firmware revisions (R200 through R500) expanded the supported I/O module count per controller node, introduced Series D I/O compatibility, and added support for FOUNDATION Fieldbus H1 linking devices.

A critical compatibility boundary exists between Series C and Series D I/O: Series C modules (CC- prefix) are not interchangeable with Series D modules (MC- prefix) without backplane and firmware upgrades. Sites running Experion PKS R210 or earlier must validate firmware compatibility before substituting any module. The C300 controller communicates over the FTE (Fault Tolerant Ethernet) backbone, which requires specific switch configurations (Cisco IE series recommended by Honeywell). As of Experion PKS R511 and later, the C300 platform entered a mature/sustaining lifecycle phase, with Honeywell directing new projects toward the C300E (Enhanced) variant. Long-term maintenance support for legacy C300 hardware remains available through third-party MRO suppliers such as DriveKNMS.

C300 Series Full Catalog & Functionalities (SKU List)

Controller Modules

CC-PCNT01 51454551-175: C300 process controller, single, up to 40 control loops
CC-PCNT02 51454551-275: C300 process controller, redundant-capable, pulse count / frequency input for flow and rotating equipment
CC-PCNT11 51454551-375: C300 enhanced controller node, expanded loop count and memory
CC-PCNT21 51454551-475: C300 controller, Series D I/O compatible, extended firmware baseline

Analog Input Modules

CC-PAIH01 51405038-175: 8-channel analog input, HART-enabled, 4–20 mA, single-ended
CC-PAIH02 51405038-275: 16-channel analog input, HART-enabled, 4–20 mA, multiplexed
CC-PAIN01 51405038-375: 8-channel analog input, non-HART, 4–20 mA / 1–5 VDC

Analog Output Modules

CC-PAOH01 51405039-175: 8-channel analog output, HART-enabled, 4–20 mA
CC-PAOH02 51405039-275: 16-channel analog output, HART-enabled, 4–20 mA

Digital Input Modules

CC-PDIL01 51405040-175: 32-channel digital input, 24 VDC, isolated, Series C
CC-PDIL02 51405040-275: 32-channel digital input, 120 VAC, isolated, Series C
CC-PDIL11 51405040-375: 32-channel digital input, 24 VDC, Series D compatible

Digital Output Modules

CC-PDOB01 51405041-175: 32-channel digital output, 24 VDC, sourcing, Series C
CC-PDOB02 51405041-275: 32-channel digital output, relay, dry contact, Series C

I/O Link Interface & Communication Modules

CC-IP0101 51403519-175: Series C I/O link interface module, primary channel
CC-IP0201 51403519-275: Series C I/O link interface module, secondary / redundancy channel
CC-TCNT01 51454552-175: C300 FTE communication interface, single port
CC-TCNT02 51454552-275: C300 FTE communication interface, redundant dual-port

Power Supply Modules

CC-PWR01 51454417-175: 24 VDC power supply, 10 A output, for C300 I/O chassis
CC-PWR02 51454417-275: Redundant 24 VDC power supply, hot-swap capable, for C300 chassis
