Honeywell STG74L Modules: STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0000 Gauge Pressure Transmitter

Name: Honeywell STG74L Modules: STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0000 Gauge Pressure Transmitter
Brand: Honeywell

Model: STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0000

Brand Honeywell

Series Pending

Model STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0000

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Honeywell STG74L Series Technical Notes

The Honeywell STG74L is a gauge pressure transmitter belonging to Honeywell's SmartLine ST 700 pressure transmitter family. This series has established a significant installed base across global heavy industries including petrochemical refineries, nuclear power facilities, offshore platforms, and large-scale chemical processing plants. The STG74L is engineered for direct gauge pressure measurement with a rangeability of up to 100:1, supporting process pressures from vacuum to high-pressure service. Its two-wire 4–20 mA HART output, combined with optional FOUNDATION Fieldbus and Profibus PA communication protocols, makes it a standard reference instrument in distributed control system (DCS) architectures worldwide. The series complies with IEC 61508 SIL 2 functional safety requirements, making it suitable for safety instrumented systems (SIS) in regulated process environments.

The Evolution of STG74L Architecture

The ST 700 SmartLine series, of which the STG74L is a core member, was introduced by Honeywell as a successor to the legacy ST 3000 series (model prefix STA, STD, STG). The ST 3000 platform, introduced in the 1980s and widely deployed through the 1990s, used a proprietary digital communication protocol (DE protocol) alongside 4–20 mA. The ST 700 generation, launched in the 2000s, standardized on HART 7, FOUNDATION Fieldbus H1, and Profibus PA, aligning with open fieldbus standards adopted by major DCS vendors including Honeywell Experion PKS, Emerson DeltaV, and ABB 800xA.

The STG74L specifically addresses gauge pressure measurement (as opposed to STD for differential pressure and STA for absolute pressure). Within the ST 700 family, the architecture uses a piezoresistive silicon sensor with a welded stainless steel or Hastelloy C-276 isolating diaphragm. The electronics module is field-replaceable and backward-compatible across the ST 700 range, reducing spare parts inventory complexity. Firmware upgrades are supported via HART handheld communicators (e.g., Emerson 475/375) or AMS Device Manager. Units manufactured prior to 2015 may require firmware migration for compatibility with HART 7 host systems. The ST 700 series is currently in its mature lifecycle phase; Honeywell continues to manufacture and support the line, but engineering resources are increasingly directed toward the next-generation SmartLine ST 800 platform.

STG74L Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly deployed configurations within the Honeywell STG74L gauge pressure transmitter series. Each model number encodes specific options per Honeywell's ST 700 model selection guide.

STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0000: Gauge pressure, 4–20 mA HART, SS wetted parts, 1/2 NPT process connection, LCD display, standard range.
STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0001: Same base configuration with SIL 2 functional safety certification enabled.
STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0010: Gauge pressure, HART, SS wetted parts, extended temperature range option.
STG74L-E1G000-1-A-AHB-21S-A-00A0-00-0000: Gauge pressure, HART, Hastelloy C-276 wetted diaphragm, 1/2 NPT, LCD display.
STG74L-E1G000-1-A-AHB-11S-A-10A0-00-0000: Gauge pressure, HART, SS wetted parts, remote seal option enabled.
STG74L-F1G000-1-A-AHB-11S-A-00A0-00-0000: Gauge pressure, FOUNDATION Fieldbus H1 output, SS wetted parts, LCD display.
STG74L-P1G000-1-A-AHB-11S-A-00A0-00-0000: Gauge pressure, Profibus PA output, SS wetted parts, standard configuration.
STG74L-E1G000-1-A-AHB-11S-A-00A0-10-0000: Gauge pressure, HART, SS wetted parts, integral manifold valve option.
STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0100: Gauge pressure, HART, SS wetted parts, enhanced EMI/RFI shielding option.
STG74L-E1G000-1-A-AHB-11S-A-00A0-00-1000: Gauge pressure, HART, SS wetted parts, tropical/high-humidity environmental protection.
STG74L-E1G000-1-A-AHB-31S-A-00A0-00-0000: Gauge pressure, HART, Tantalum wetted diaphragm for highly corrosive media.
STG74L-E1G000-1-A-AHB-11S-B-00A0-00-0000: Gauge pressure, HART, SS wetted parts, 1/2 BSPP process connection.
STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0000-T1: Gauge pressure, HART, SS wetted parts, factory-configured with Honeywell SIL certificate documentation package.
STG74L-E1G000-1-A-AHB-11S-A-20A0-00-0000: Gauge pressure, HART, SS wetted parts, dual-compartment housing with conduit entry option.
STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0000-C1: Gauge pressure, HART, SS wetted parts, ATEX/IECEx Zone 1 explosion-proof certification.
STG74L-E1G000-1-A-AHB-11S-A-00A0-00-0000-C2: Gauge pressure, HART, SS wetted parts, FM/CSA Class I Division 1 North American hazardous area certification.

Quality Control for the STG74L Range

Each STG74L unit processed by DriveKNMS undergoes a structured inspection and functional verification protocol specific to the ST 700 platform architecture:

Visual and Mechanical Inspection: Housing integrity check, diaphragm surface examination for pitting or corrosion, process connection thread verification, terminal block and wiring compartment inspection.
Electronics Module Verification: Firmware version identification via HART communicator; comparison against Honeywell firmware compatibility matrix for the target DCS host.
Sensor Characterization: Zero and span calibration across the full configured range using a deadweight tester or precision pressure calibrator traceable to NIST standards. Linearity, hysteresis, and repeatability are verified per IEC 60770-1.
HART Communication Test: Full HART 5/7 command set verification including PV, SV, TV, QV readback; device variable mapping confirmation; burst mode functionality check.
Output Loop Test: 4–20 mA output accuracy verification at 0%, 25%, 50%, 75%, and 100% of calibrated span.
Insulation Resistance Test: 500 VDC megohm test between circuit and housing to verify electrical isolation integrity.
Final Documentation: Calibration certificate with as-found and as-left data, firmware version record, and inspection report issued with each unit.
