Mitsubishi FX3U-32MR/DS CPU Unit

Model: FX3U-32MR/DS

Brand Mitsubishi Electric

Series MELSEC-FX

Model FX3U-32MR/DS

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Mitsubishi FX3U Series: Comprehensive Module Range and Technical Overview

The Mitsubishi FX3U series represents the third-generation flagship of Mitsubishi Electric's MELSEC FX compact PLC family. Deployed extensively across global heavy industry — including petrochemical plants, nuclear auxiliary systems, refinery control loops, and automotive assembly lines — the FX3U platform has established a dominant installed base in Asia-Pacific, Europe, and the Americas. Its 32-bit RISC CPU architecture, high-speed pulse output (up to 100 kHz on 6 axes), and native USB programming port made it the de facto standard for standalone machine control from its introduction in 2004 through the mid-2010s. The FX3U-32MR/DS specifically is a 32 I/O relay output CPU unit operating on DC power supply (24 VDC), with 16 inputs and 16 relay outputs, suited for applications requiring isolated output switching in harsh electrical environments.

The Evolution of FX3U Architecture

The FX lineage began with the FX0/FX0N series in the early 1990s, progressing through FX1N, FX2N, and FX2NC before the FX3U was introduced as a high-performance successor. The FX3U retained backward compatibility with FX2N expansion modules via adapter blocks, a critical design decision that protected existing installations. Its successor, the FX5U (introduced ~2014), migrated to Ethernet-native communication and a 64-bit architecture, rendering FX3U a mature/legacy platform. However, the FX3U remains in active production and is supported under Mitsubishi's long-term maintenance policy. Facilities running FX3U-based systems face compatibility constraints when integrating with newer CC-Link IE Field networks, typically requiring gateway modules (e.g., FX3U-ENET-ADP) as bridging solutions. The FX3U-32MR/DS variant uses a DC power supply input, distinguishing it from the FX3U-32MR/ES (AC supply) in the same I/O class.

FX3U Full Catalog & Functionalities (SKU List)

CPU Units

FX3U-16MR/ES: 16 I/O relay output CPU, AC supply
FX3U-32MR/DS: 32 I/O relay output CPU, DC 24V supply — current item
FX3U-32MR/ES: 32 I/O relay output CPU, AC supply
FX3U-48MR/ES: 48 I/O relay output CPU, AC supply
FX3U-64MR/ES: 64 I/O relay output CPU, AC supply
FX3U-80MR/ES: 80 I/O relay output CPU, AC supply
FX3U-128MR/ES: 128 I/O relay output CPU, AC supply, max base config
FX3U-32MT/ES: 32 I/O transistor sink output CPU, AC supply
FX3U-32MT/ESS: 32 I/O transistor source output CPU, AC supply
FX3U-64MT/ES: 64 I/O transistor sink output CPU, AC supply

Communication & Network Adapters

FX3U-ENET: Ethernet communication module, 10/100 Mbps, left-side mount
FX3U-ENET-ADP: Ethernet adapter for FX3U/FX3UC, compact form factor
FX3U-232ADP-MB: RS-232C adapter with MODBUS RTU master/slave support
FX3U-485ADP-MB: RS-485 adapter with MODBUS RTU, multi-drop capable
FX3U-USB-BD: USB function expansion board for programming port

Special Function & Analog Modules

FX3U-4AD: 4-channel analog input module, 12-bit resolution
FX3U-4DA: 4-channel analog output module, 12-bit resolution
FX3U-4AD-PT-ADP: 4-channel PT100 temperature input adapter
FX3U-4AD-TC-ADP: 4-channel thermocouple input adapter (K/J/T/E/R/S/B)
FX3U-1PG: Single-axis pulse generator module, 200 kHz max output
FX3U-20SSC-H: 2-axis SSCNET III servo positioning module

Sourcing Hard-to-Find & Obsolete FX3U Parts

Quality Control for the FX3U Range

FX3U CPU units and expansion modules undergo a structured inspection protocol at DriveKNMS prior to dispatch. Each CPU unit is powered on and connected via GX Works2 or GX Developer to verify firmware version, I/O point mapping, and program memory integrity. Relay output modules are cycled under resistive load to confirm contact closure and release timing within Mitsubishi's published specifications (relay life: 200,000 operations minimum under rated load). For communication adapters (RS-232C, RS-485, Ethernet), loopback tests and MODBUS frame exchange tests are performed. Backplane bus integrity is verified by installing the module into a known-good FX3U base and executing a full I/O diagnostic scan. Units exhibiting any parameter deviation are quarantined and not listed as available stock. Test records are retained for 24 months and available to customers upon request.
