Schneider Electric Altivar ATV340 Drives — ATV340D15N4

Technical Dossier

Product Details And Specifications

Schneider Electric Altivar ATV340 Series: Comprehensive Module Range and Technical Overview

The Schneider Electric Altivar ATV340 series is a line of variable speed drives (VSDs) engineered for high-demand industrial applications including process automation, pump and fan control, compressor management, and conveyor systems. Deployed extensively across petrochemical refineries, water treatment facilities, offshore platforms, and continuous-process manufacturing plants, the ATV340 occupies a critical position in the global installed base of IEC-compliant motor control infrastructure. Its architecture supports both standalone drive operation and deep integration into distributed control systems (DCS) and programmable logic controller (PLC) networks via industrial fieldbus protocols including EtherNet/IP, Modbus TCP, PROFIBUS DP, CANopen, and DeviceNet.

The ATV340 series covers a power range from 0.37 kW to 75 kW (400 V three-phase), with dedicated variants for 200 V and 600 V supply networks. Its IP21/IP55 enclosure options and integrated EMC filters make it suitable for both panel-mount and standalone cabinet installations in harsh industrial environments.

📩 Looking for a specific ATV340 model? Send your part list to: sale@driveknms.com

The Evolution of ATV340 Architecture

The ATV340 is the direct successor to the Altivar 312 and Altivar 320 platforms, consolidating their feature sets while introducing a unified commissioning interface via the SoMove software suite and the Altivar Process ATV600/ATV900 ecosystem compatibility layer. Early Altivar drives (ATV11, ATV18, ATV28) used proprietary serial communication and analog I/O-only control. The ATV312 introduced CANopen and Modbus RTU as standard. The ATV320 added EtherNet/IP and PROFIBUS DP options via plug-in communication cards.

The ATV340 retains backward-compatible parameter structures with the ATV320, reducing re-engineering time during panel upgrades. Its dual-port EtherNet/IP interface supports Device Level Ring (DLR) topology — a key requirement for high-availability process lines. The integrated safety function STO (Safe Torque Off) to SIL 2 / PLd eliminates the need for external safety relays in most machine safety architectures.

As of 2024, the ATV340 series is in active production and full lifecycle support. Schneider Electric has confirmed continued availability through at least 2030, with spare parts and firmware updates committed beyond that horizon. Legacy ATV312 and ATV320 units in the field are increasingly being replaced by ATV340 during scheduled maintenance windows.

ATV340 Full Catalog & Functionalities (SKU List)

The following SKUs represent the verified production range of the Altivar ATV340 series, classified by power rating and supply voltage. Each entry reflects a distinct catalog reference with defined power, current, and enclosure specifications.

ATV340U07N4: 0.75 kW / 400 V 3-phase, IP21, integrated EMC filter, STO SIL2
ATV340U15N4: 1.5 kW / 400 V 3-phase, IP21, Modbus TCP + CANopen standard
ATV340U22N4: 2.2 kW / 400 V 3-phase, IP21, dual-port EtherNet/IP ready
ATV340U30N4: 3.0 kW / 400 V 3-phase, IP21, DLR topology support
ATV340U40N4: 4.0 kW / 400 V 3-phase, IP21, integrated braking transistor
ATV340U55N4: 5.5 kW / 400 V 3-phase, IP21, PROFIBUS DP via VW3A3607 card
ATV340U75N4: 7.5 kW / 400 V 3-phase, IP21, DeviceNet via VW3A3609 card
ATV340D11N4: 11 kW / 400 V 3-phase, IP21, SoMove parameter backup compatible
ATV340D15N4: 15 kW / 400 V 3-phase, IP21, full fieldbus suite, STO SIL2/PLd — current page reference SKU
ATV340D18N4: 18.5 kW / 400 V 3-phase, IP21, motor fluxing control, auto-tuning
ATV340D22N4: 22 kW / 400 V 3-phase, IP21, energy savings mode, PID controller
ATV340D30N4: 30 kW / 400 V 3-phase, IP21, dynamic braking resistor terminal
ATV340D37N4: 37 kW / 400 V 3-phase, IP21, high-inertia load compensation
ATV340D45N4: 45 kW / 400 V 3-phase, IP21, forced cooling fan, extended I/O
ATV340D55N4: 55 kW / 400 V 3-phase, IP21, cabinet-mount, DC bus sharing
ATV340D75N4: 75 kW / 400 V 3-phase, IP21, maximum frame size, common DC bus
ATV340U07N4E: 0.75 kW / 400 V, IP55 outdoor-rated enclosure variant
ATV340U15N4E: 1.5 kW / 400 V, IP55 with conformal coating for humid environments
ATV340D15N4E: 15 kW / 400 V, IP55 variant of the D15N4 — direct field-hardened equivalent

Sourcing Hard-to-Find & Obsolete ATV340 Parts

DriveKNMS maintains a dedicated inventory program for the Altivar ATV340 series and its predecessor platforms (ATV312, ATV320). For end-users operating legacy installations where OEM lead times exceed operational tolerances, DriveKNMS provides the following sourcing services:

• New-in-box (NIB) stock from authorized distribution channels with full traceability documentation
• Reconditioned units with full functional test reports and 12-month warranty
• Cross-reference matching for discontinued ATV312/ATV320 catalog numbers to ATV340 equivalents
• Emergency same-day dispatch for critical process shutdowns
• Long-term consignment stocking agreements for OEM and EPC contractors

For obsolete communication cards (VW3A3601 through VW3A3609) and keypad accessories (VW3A1101, VW3A1102), DriveKNMS maintains separate inventory pools with individual test certification.

Quality Control for the ATV340 Range

Each ATV340 unit processed through DriveKNMS undergoes a structured inspection and functional test protocol designed around the drive’s internal architecture:

• Power stage verification: IGBT gate drive integrity test, DC bus capacitance measurement, and inrush current characterization
• Control board diagnostics: Firmware version confirmation, parameter memory read/write cycle test, and I/O channel continuity check
• Fieldbus communication test: Live Modbus TCP and EtherNet/IP polling via test PLC to confirm register map integrity
• STO function validation: Safe Torque Off channel activation test per IEC 62061 SIL 2 verification procedure
• Thermal cycling: Load test at rated current for minimum 30 minutes with thermal imaging of heatsink and IGBT module
• Enclosure inspection: IP rating integrity check, terminal block torque verification, and EMC filter continuity

All test results are documented and supplied with each unit shipment. Reconditioned units include a before/after parameter comparison report.

📩 Contact Information

Email: sale@driveknms.com
WhatsApp: +86 18359293191
Web: driveknms.com
© 2026 DriveKNMS. All trademarks belong to their respective owners. Specifications are for reference only and subject to change without notice. Verify all parameters against official documentation before installation.
