Siemens SINAMICS S120 Capacitor Module 6SL3100-1CE14-0AA0

Name: Siemens SINAMICS S120 Capacitor Module 6SL3100-1CE14-0AA0
Brand: Siemens

Model: 6SL3100-1CE14-0AA0

Brand Siemens

Series SINAMICS

Model 6SL3100-1CE14-0AA0

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Siemens SINAMICS S120 Series Technical Notes

The Evolution of SINAMICS S120 Architecture

The SINAMICS S120 platform was introduced by Siemens in the early 2000s as a successor to the SIMODRIVE 611 series. The initial release established the booksize and chassis format distinction, with booksize modules targeting compact multi-axis cabinet installations and chassis units addressing high-power single-axis applications. The DRIVE-CLiQ communication interface was introduced as the backbone for encoder feedback, motor data identification, and topology recognition — replacing the legacy encoder cable standards used in SIMODRIVE 611.

Firmware generations have progressed from V2.x through V5.x (current), each adding functional safety extensions (STO, SS1, SLS, SDI per IEC 62061 / EN ISO 13849), expanded motor compatibility (including linear and torque motors), and enhanced diagnostics via STARTER and Startdrive commissioning tools. Compatibility between firmware generations requires careful management: modules manufactured before 2012 may require hardware revision checks before firmware upgrades beyond V4.7. The 6SL3100 sub-family (Line-side components and supplementary modules) has remained architecturally stable across these generations, though specific hardware revisions (e.g., -0AA0 vs -0AA1) affect interchangeability and must be verified against the project-specific hardware configuration.

SINAMICS S120 Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly stocked components within the SINAMICS S120 ecosystem, organized by functional category:

Capacitor & Braking Modules

6SL3100-1CE14-0AA0: Capacitor Module, booksize, DC link buffer for ride-through
6SL3100-1CE21-0AA0: Capacitor Module, booksize, extended energy storage capacity
6SL3100-1BE31-0AA0: Braking Module, booksize, 25 kW peak braking power
6SL3100-1BE21-0AA0: Braking Module, booksize, 10 kW continuous / 50 kW peak

Active Line Modules (ALM)

6SL3130-7TE21-6AA3: Active Line Module, 16 kW, booksize, regenerative feedback
6SL3130-7TE23-6AA3: Active Line Module, 36 kW, booksize, low-harmonic infeed
6SL3130-7TE28-0AA3: Active Line Module, 80 kW, booksize, integrated line filter
6SL3330-7TE32-1AA3: Active Line Module, 210 kW, chassis format, regenerative

Smart Line Modules (SLM)

6SL3130-6AE21-0AB0: Smart Line Module, 16 kW, booksize, non-regenerative
6SL3130-6AE23-6AB0: Smart Line Module, 36 kW, booksize, non-regenerative

Motor Modules (Single-Axis & Double-Axis)

6SL3120-1TE21-0AA3: Single Motor Module, 10 A, booksize, vector/servo control
6SL3120-1TE23-0AA3: Single Motor Module, 30 A, booksize, vector/servo control
6SL3120-2TE21-0AA3: Double Motor Module, 2×9 A, booksize, dual-axis servo
6SL3120-2TE23-0AA3: Double Motor Module, 2×18 A, booksize, dual-axis servo

Control Units

6SL3040-1MA00-0AA0: CU320-2 PN Control Unit, PROFINET, multi-axis coordination
6SL3040-1MA01-0AA0: CU320-2 DP Control Unit, PROFIBUS, multi-axis coordination
6SL3055-0AA00-5BA0: SMC10 Sensor Module Cabinet, resolver feedback interface
6SL3055-0AA00-5CA0: SMC20 Sensor Module Cabinet, incremental encoder interface

Quality Control for the SINAMICS S120 Range

SINAMICS S120 modules present specific test challenges due to their integrated DRIVE-CLiQ topology reporting, DC bus interconnection via busbars, and firmware-dependent parameter sets. DriveKNMS applies the following test protocol to all S120 units processed:
