Triconex 3624 Digital Output Module: Specs, Models & Availability

Technical Dossier

Product Details And Specifications

Triconex Tricon Series: Comprehensive Module Range and Technical Overview

The Triconex Tricon platform is one of the most widely deployed Safety Instrumented System (SIS) architectures in global heavy industry. Installed across petrochemical complexes, nuclear power stations, offshore platforms, LNG terminals, and refinery process units, the Tricon system operates on a Triple Modular Redundant (TMR) architecture — three independent processing paths with continuous voting logic — delivering IEC 61511 / IEC 61508 SIL 3 compliance. The Triconex 3624 is a 32-channel Digital Output Module within this platform, designed for high-density discrete output control in safety-critical shutdown and control loops.

The Evolution of Tricon Architecture

The Triconex Tricon system was introduced in the 1980s as one of the first commercially available TMR-based safety controllers. Early generations (Tricon v1–v7) used proprietary backplane communication and were limited to specific I/O module families. The transition to Tricon v9 and v10 introduced enhanced diagnostics, faster scan rates, and expanded I/O density — including high-channel-count modules such as the 3624. The Tricon Communication Module (TCM) enabled Modbus and TriStation 1131 integration, while later revisions added OPC-DA/UA support for DCS interoperability with systems such as Honeywell Experion, Emerson DeltaV, and Yokogawa CENTUM. Compatibility between module generations is constrained by chassis type (7-slot vs. 14-slot), firmware revision, and Main Processor Module (MP) version. Mixing module generations without firmware alignment is a documented failure mode in lifecycle management.

Tricon Full Catalog & Functionalities (SKU List)

Main Processor & Controller Modules

• 3008: Main Processor Module (MP), TMR architecture, TriStation 1131 compatible
• 3006: Main Processor Module, earlier generation, v9 firmware baseline
• 3007: Main Processor Module, enhanced diagnostics, v10 compatible
• 3009: Enhanced Main Processor Module, high-speed scan, dual-port Ethernet

Digital Input Modules

• 3501: 32-channel Digital Input Module, 24 VDC, TMR voting
• 3503: 32-channel Digital Input Module, 120 VAC, isolated inputs
• 3504: 32-channel Digital Input Module, 24 VDC, enhanced diagnostics
• 3511: 16-channel Digital Input Module, 24 VDC, high-current sensing

Digital Output Modules

• 3601: 16-channel Digital Output Module, 24 VDC, solid-state relay
• 3603: 16-channel Digital Output Module, 120 VAC, triac output
• 3607: 32-channel Digital Output Module, 24 VDC, low-power variant
• 3624: 32-channel Digital Output Module, 24 VDC, high-density discrete output for SIS shutdown loops
• 3625: 32-channel Digital Output Module, 120 VAC, isolated solid-state outputs

Analog Input / Output Modules

• 3700: 8-channel Analog Input Module, 4–20 mA, 12-bit resolution
• 3703: 8-channel Analog Input Module, ±10 VDC / 4–20 mA, configurable
• 3805E: 8-channel Analog Output Module, 4–20 mA, SIL 2 rated

Communication & Power Modules

• 4351B: Tricon Communication Module (TCM), Modbus RTU/TCP, OPC-DA
• 4119A: Power Supply Module, 24 VDC input, redundant configuration

Sourcing Hard-to-Find & Obsolete Tricon Parts

The Triconex Tricon platform entered its mature/end-of-active-production phase for several module families. Schneider Electric (current IP holder post-Invensys acquisition) has issued end-of-life notices for select Tricon v9 modules. For facilities operating legacy Tricon installations — particularly those with 10–25 year operational horizons common in nuclear and refinery environments — sourcing certified replacement modules is a primary lifecycle challenge.

DriveKNMS maintains a dedicated inventory of Tricon spare parts including the 3624, sourced from decommissioned systems, factory-surplus stock, and authorized redistribution channels. All units are subject to pre-shipment functional verification. Long-term maintenance contracts and consignment stocking programs are available for operators requiring guaranteed module availability across multi-year turnaround cycles.

Quality Control for the Tricon Range
