Yaskawa DX200 Robot Controller Modules: JANCD-XCP01C, JZNC-XIU01B, OJANCD-YSF22B-E & Full Series Specs

Technical Dossier

Product Details And Specifications

Yaskawa DX200 Series: Comprehensive Module Range and Technical Overview

The Yaskawa DX200 is a multi-robot controller platform deployed across heavy industrial sectors including automotive assembly, chemical processing, nuclear facility maintenance, and oil refinery operations. Introduced as the successor to the NX100 and XRC controller families, the DX200 supports coordinated control of up to eight robots or 72 axes simultaneously. Its architecture is built on a dual-CPU structure separating motion control from system management, enabling deterministic real-time performance in safety-critical environments. The DX200 is certified to ISO 10218-1 and IEC 62061 SIL2/PLd functional safety standards, making it a reference platform for process industries requiring certified robot safety integration. Global installed base spans Tier 1 automotive OEMs, petrochemical complexes, and nuclear decommissioning contractors across North America, Europe, and Asia-Pacific.

The Evolution of DX200 Architecture

Yaskawa's robot controller lineage progressed through distinct generations: the YASNAC MRC (1988), XRC (1998), NX100 (2003), DX100 (2007), and DX200 (2011). Each generation introduced expanded axis count, improved safety architecture, and updated fieldbus compatibility. The XRC platform used the JZNC-XIU01B I/O unit and JANCD-XCP01C CPU board — both of which remain in active service in legacy XRC installations and are cross-referenced in DX200 spare parts documentation for retrofit and migration projects. The DX200 introduced a 32-bit dual-processor architecture replacing the XRC's single-board design, added integrated functional safety (FSU) without external safety PLCs, and expanded network support to EtherNet/IP, DeviceNet, PROFIBUS-DP, and CC-Link. The OJANCD-YSF22B-E safety function board is specific to DX200 and handles the dual-channel safety monitoring required for collaborative and hazardous-area deployments. Backward compatibility with XRC-era I/O wiring harnesses was maintained through adapter modules, reducing retrofit costs in brownfield installations.

DX200 Full Catalog & Functionalities (SKU List)

The following SKUs represent the verified DX200 and cross-referenced XRC module catalog. Each entry reflects a discrete hardware function within the controller backplane or pendant interface.

JANCD-XCP01C: DX200 main CPU board; dual-processor motion and system control.
JANCD-XCP01C-1: Revised CPU board variant with updated firmware compatibility for DX200 Rev.2+.
OJANCD-YSF22B-E: DX200 safety function board; dual-channel FSU monitoring, SIL2/PLd certified.
JZNC-XIU01B: XRC-series I/O interface unit; 24VDC digital I/O, compatible with DX200 via adapter.
JANCD-XIO02B: DX200 I/O expansion board; 32 DI / 32 DO, 24VDC sink/source.
JANCD-XIO03B: High-density I/O board; 64 DI / 64 DO for multi-robot cell integration.
JANCD-XEW02B: EtherNet/IP communication board; supports implicit and explicit messaging.
JANCD-XPB02B: PROFIBUS-DP slave communication board; up to 12Mbps.
JANCD-XCC02B: CC-Link slave communication board; Ver.1.10 compliant.
JANCD-XRW02B: DeviceNet slave communication board; Group 2 only server.
JANCD-XFU01B: Functional safety unit board; external safety signal processing for DX200 FSU.
JANCD-XMS02B: Servo amplifier interface board; connects DX200 CPU to SGDV/SGDH servo drives.
JANCD-XPW01B: Internal power supply board; generates ±15V, +5V, +24V rails for backplane.
JANCD-XBK01B: Brake control board; manages servo brake release sequencing for all axes.
JANCD-XTU01B: Teaching pendant interface board; USB and serial pendant communication.
JANCD-XRK01B: Rack backplane board; passive bus for DX200 module interconnection.
JZNC-YRK01B-1E: XRC rack unit; houses XRC-series boards in legacy installations.
SGDV-2R8A01B: SERVOPACK amplifier; 200V, 0.5kW, compatible with DX200 servo interface.

Sourcing Hard-to-Find & Obsolete DX200 Parts

The DX200 controller entered its mature lifecycle phase after 2020, with Yaskawa transitioning new installations to the YRC1000 and YRC1000micro platforms. As a result, several DX200 board-level components — particularly the OJANCD-YSF22B-E safety board, JANCD-XCP01C CPU variants, and XRC-era cross-reference modules such as the JZNC-XIU01B — are no longer available through standard distribution channels. DriveKNMS maintains a dedicated inventory of tested DX200 and XRC spare modules sourced from decommissioned cells, authorized surplus channels, and factory-refurbished stock. For end-users operating DX200 systems beyond the standard 10-year parts support window, DriveKNMS provides lifecycle extension services including board-level repair, functional testing, and long-term consignment stocking agreements. All sourced modules are verified against Yaskawa's original part numbers and revision codes prior to dispatch.

Quality Control for the DX200 Range

DX200 modules operate on a proprietary high-speed backplane bus running at 100Mbps between the CPU, I/O, and communication boards. Standard bench testing is insufficient to validate backplane bus integrity or safety channel continuity. DriveKNMS applies a DX200-specific test protocol that includes: powered backplane bus communication verification using a reference DX200 rack; dual-channel safety signal injection testing for FSU boards (OJANCD-YSF22B-E); servo interface loopback testing for JANCD-XMS02B; EtherNet/IP and PROFIBUS-DP network enumeration for communication boards; and 72-hour thermal soak at 55°C to screen for latent component failures. CPU boards (JANCD-XCP01C series) are tested with a known-good firmware image and verified for correct boot sequence, memory integrity, and pendant communication handshake. All test results are documented and shipped with each module.
