Yaskawa SGMSH Servo Motors SGMSH-15ACA-TV11

Technical Dossier

Product Details And Specifications

Yaskawa SGMSH Series Technical Notes

The Evolution of SGMSH Architecture

The SGMSH series was introduced as part of Yaskawa's Sigma-II platform in the late 1990s, succeeding the Sigma-I (SGMD/SGMG) generation. The core architectural advancement was the integration of a 17-bit incremental encoder (standard) and optional 17-bit absolute encoder, replacing the earlier 13-bit resolvers. This increased positioning resolution from 8,192 pulses/rev to 131,072 pulses/rev, enabling sub-micron repeatability in precision axes.

Q: How are RFQ terms confirmed?
A: Quantity, required condition, documentation needs, destination and sourcing route are confirmed during RFQ review before quotation.

Compatibility note: SGMSH motors require SGDH-series SERVOPACKs with matching capacity codes. They are not directly interchangeable with Sigma-V (SGMGV) or Sigma-7 (SGMGV7) motors without drive replacement, due to encoder protocol differences (MECHATROLINK-II vs. MECHATROLINK-III). For facilities planning long-term maintenance, DriveKNMS maintains cross-reference documentation for upgrade path planning.

SGMSH Full Catalog & Functionalities (SKU List)

The following SKUs represent the verified SGMSH production range. All models are AC servo motors in the Sigma-II high-inertia frame class, rated for 200 VAC three-phase input unless noted.

SGMSH-01ACA61: 100 W, 17-bit incremental encoder, standard shaft, no brake — entry-level SGMSH for light auxiliary axes.
SGMSH-02ACA61: 200 W, 17-bit incremental encoder, standard shaft, no brake — compact frame for positioning tables.
SGMSH-04ACA61: 400 W, 17-bit incremental encoder, standard shaft, no brake — mid-range output for conveyor drives.
SGMSH-05ACA61: 500 W, 17-bit incremental encoder, standard shaft, no brake — standard workhorse for single-axis CNC.
SGMSH-08ACA61: 750 W, 17-bit incremental encoder, standard shaft, no brake — high-torque density for rotary indexers.
SGMSH-10ACA61: 1.0 kW, 17-bit incremental encoder, standard shaft, no brake — common in packaging line servo axes.
SGMSH-15ACA61: 1.5 kW, 17-bit incremental encoder, standard shaft, no brake — baseline 1.5 kW SGMSH without brake option.
SGMSH-15ACA-TV11: 1.5 kW, 17-bit incremental encoder, standard shaft, with 24 VDC holding brake — the subject SKU; used in vertical axes requiring fail-safe brake engagement on power loss.
SGMSH-20ACA61: 2.0 kW, 17-bit incremental encoder, standard shaft, no brake — heavy-duty feed axis for milling machines.
SGMSH-20ACA-TV11: 2.0 kW, 17-bit incremental encoder, standard shaft, with holding brake — vertical axis variant for 2 kW class.
SGMSH-30ACA61: 3.0 kW, 17-bit incremental encoder, standard shaft, no brake — large-frame SGMSH for heavy gantry axes.
SGMSH-30ACA-TV11: 3.0 kW, 17-bit incremental encoder, standard shaft, with holding brake — crane and hoist auxiliary servo.
SGMSH-50ACA21: 5.0 kW, 17-bit incremental encoder, standard shaft, no brake — high-power SGMSH for main spindle assist.
SGMSH-50ACA-TV11: 5.0 kW, 17-bit incremental encoder, standard shaft, with holding brake — 5 kW vertical axis with brake.
SGMSH-80ACA21: 7.5 kW, 17-bit incremental encoder, large frame, no brake — maximum-frame SGMSH for heavy industrial drives.
SGMSH-1AACA21: 11 kW, 17-bit incremental encoder, large frame, no brake — top-tier SGMSH output class for rolling mill axes.

Sourcing Hard-to-Find & Obsolete SGMSH Parts

Q: How is condition confirmed before quotation?
A: Available condition, photos, test records and documentation are checked according to the requested model and sourcing channel before a formal RFQ response.

Quality Control for the SGMSH Range

Each SGMSH unit processed by DriveKNMS undergoes a structured inspection protocol specific to the Sigma-II motor architecture:
