The YOKOGAWA ALE111 series is a line of Ethernet communication modules designed for integration within YOKOGAWA's STARDOM FCN/FCJ autonomous controllers and the broader Vnet/IP distributed control architecture. These modules are deployed across critical continuous-process industries including petroleum refining, chemical manufacturing, LNG terminals, nuclear power auxiliary systems, and offshore platform automation. The ALE111 series provides the physical and protocol-layer Ethernet interface that connects FCN/FCJ controller nodes to plant-wide supervisory networks, historian servers, and HMI stations. Its deterministic communication behavior and support for industrial Ethernet standards make it a load-bearing component in high-availability DCS topologies where network redundancy and fault isolation are mandatory requirements.

The Evolution of ALE111 Architecture

The ALE111 module was introduced as part of YOKOGAWA's transition from proprietary fieldbus architectures toward open industrial Ethernet standards within the STARDOM platform. Early FCN/FCJ deployments relied on dedicated serial and proprietary bus interfaces; the ALE111 represented the shift to 100BASE-TX Ethernet as the primary inter-node communication medium. Successive hardware revisions addressed EMI compliance requirements for IEC 61000-series environments, expanded VLAN tagging support, and improved hot-standby switchover timing for redundant network configurations. The S1 suffix on the ALE111-S00 S1 designates a specific hardware revision level that determines firmware compatibility and backplane interface signaling. Integrators managing mixed-revision FCN/FCJ racks must verify revision compatibility before substituting modules, as backplane protocol differences between major revisions are not always backward-compatible. As YOKOGAWA's product roadmap has shifted toward the OpreX Control and Safety System architecture, the ALE111 series has entered a mature/sustaining lifecycle phase. New greenfield projects are directed toward successor platforms, but the installed base of ALE111-equipped FCN/FCJ systems in long-lifecycle industries (refining, nuclear, chemical) ensures continued demand for spare and replacement modules through at least the 2030s.

ALE111 Full Catalog & Functionalities (SKU List)

The following SKUs represent verified models within the YOKOGAWA ALE111 and directly associated FCN/FCJ communication module range. Each entry reflects a distinct hardware configuration or revision level.

ALE111-S00 S1: FCN/FCJ 100BASE-TX Ethernet communication module, hardware revision S1, standard single-port configuration.
ALE111-S00 S2: Ethernet communication module, hardware revision S2, updated EMI shielding and firmware baseline.
ALE111-S00 S3: Ethernet communication module, hardware revision S3, extended operating temperature tolerance.
ALE111-S10: Dual-port Ethernet communication module for redundant network ring topologies.
ALE111-S10 S1: Dual-port variant, hardware revision S1, supports RSTP (Rapid Spanning Tree Protocol).
ALE111-S10 S2: Dual-port variant, hardware revision S2, improved port isolation and diagnostics.
FCN-RTU ALE111: ALE111 module configured for FCN-RTU remote terminal unit deployments in pipeline SCADA applications.
ALE111 (CE Mark): European conformity variant with additional EMC certification documentation for EU installations.
ALE111 (UL Listed): UL 508 listed variant for North American industrial panel installations.
ALE111 Replacement Kit: Factory-authorized replacement assembly including module, backplane connector, and installation guide.
FCJ-ALE111-S00: ALE111 communication module variant factory-configured for FCJ compact controller chassis.
ALE111 (Hot Standby Pair): Matched pair of ALE111 modules pre-validated for hot-standby redundant Ethernet configurations.
ALE111 (Vnet/IP Node): ALE111 configured as a Vnet/IP network node interface for integration with CENTUM VP supervisory layer.
ALE111 (HART Pass-Through): Variant supporting HART protocol pass-through over Ethernet for field device diagnostics.
ALE111 (Modbus TCP): ALE111 with Modbus TCP/IP gateway function enabled for third-party SCADA integration.
ALE111 (OPC-UA Ready): Firmware-updated ALE111 supporting OPC Unified Architecture server function for IIoT data access.
ALE111 (DNP3 Gateway): ALE111 variant with DNP3 over TCP/IP for utility and substation automation applications.
