Allen-Bradley FLEX I/O Modules: 1794-IB16XT,

Name: Allen-Bradley FLEX I/O Modules: 1794-IB16XT,
Brand: Allen-Bradley

Model: 1794-IB16XT

Brand Allen-Bradley

Series FLEX

Model 1794-IB16XT

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Allen-Bradley FLEX I/O Series Technical Notes

The 1794-IB16XT, the subject of this page, is a 16-channel digital DC input module rated for extended temperature operation (-20°C to +60°C), designed for installations in uncontrolled or harsh ambient environments where standard-range modules are not rated for use.

The Evolution of FLEX I/O Architecture

The FLEX I/O platform was introduced in the mid-1990s as Rockwell Automation's answer to the demand for distributed, rack-independent I/O that could be mounted close to field devices, reducing wiring runs and cabinet footprint. The original 1794 series communicated via the 1794-ADN DeviceNet Adapter, positioning it within Allen-Bradley's DeviceNet ecosystem alongside the SLC 500 and early ControlLogix controllers.

As fieldbus standards evolved, Rockwell expanded the adapter portfolio to include ControlNet (1794-ACN/ACNR), EtherNet/IP (1794-AENT/AENTR), PROFIBUS DP (1794-APB), and Remote I/O (1794-ASB). This multi-network compatibility allowed the same physical I/O modules to be reused across different communication backbones, protecting capital investment during control system migrations.

Q: How are RFQ terms confirmed?
A: Quantity, required condition, documentation needs, destination and sourcing route are confirmed during RFQ review before quotation.

FLEX I/O Full Catalog & Functionalities (SKU List)

Digital Input Modules (DI)

1794-IB16: 16-channel 24VDC sink digital input, standard temperature range
1794-IB16XT: 16-channel 24VDC sink digital input, extended temperature (-20°C to +60°C)
1794-IB32: 32-channel 24VDC sink digital input, high-density configuration
1794-IM8: 8-channel 120VAC digital input module for legacy AC field devices
1794-IV16: 16-channel 24VDC source (IEC Type 1) digital input module

Digital Output Modules (DO)

1794-OB16: 16-channel 24VDC source digital output, 0.5A per channel
1794-OB16XT: 16-channel 24VDC source digital output, extended temperature
1794-OB32: 32-channel 24VDC source digital output, high-density
1794-OW8: 8-channel relay output module, Form A contacts, 2A per channel
1794-OA8: 8-channel 120/240VAC triac output module

Analog Input/Output Modules (AI/AO)

1794-IE8: 8-channel analog current input, 4–20mA, 12-bit resolution
1794-IE8XT: 8-channel analog current input, extended temperature variant
1794-OE4: 4-channel analog current output, 4–20mA, 12-bit resolution
1794-IF4I: 4-channel isolated analog input, voltage/current selectable
1794-OF4I: 4-channel isolated analog output, voltage/current selectable

Communication Adapters

1794-AENT: EtherNet/IP adapter, single-port, supports up to 8 I/O modules per bank
1794-AENTR: EtherNet/IP adapter with embedded DLR switch for ring topology redundancy
1794-ACN15: ControlNet adapter, coax media, supports scheduled and unscheduled messaging
1794-ADN: DeviceNet adapter, supports explicit and I/O messaging
1794-APB: PROFIBUS DP adapter, slave mode, up to 244 bytes I/O

Power Supplies & Terminal Bases

1794-TB3: 3-wire terminal base for standard I/O modules
1794-TB3S: 3-wire terminal base with side-mount wiring
1794-PS13: 24VDC power supply module for FLEX I/O bank

Sourcing Hard-to-Find & Obsolete FLEX I/O Parts

A significant portion of the 1794 FLEX I/O catalog has transitioned to RFQ availability review or end-of-life status as Rockwell Automation shifts its installed base toward the FLEX 5000 (5094) platform. For end users operating continuous-process facilities — where a control system migration is a multi-year capital project — the ability to source replacement 1794 modules on demand is a direct operational requirement.

Quality Control for the FLEX I/O Range

FLEX I/O modules present specific verification challenges due to their backplane bus interface and terminal base dependency. A module that passes basic power-on self-test may still exhibit communication faults when installed in a live bank due to degraded backplane connectors, corrupted firmware, or failed internal bus transceivers.

Continue The Model Path

Use system, brand and series routes to compare related published models.

Move from this exact model into the matching system hub, brand archive, model-family archive or lifecycle sourcing route before sending a final RFQ list.
