Allen-Bradley 2711P Series Modules – 2711P-RP7

Technical Dossier

Product Details And Specifications

Allen-Bradley 2711P Series Technical Notes

The Allen-Bradley 2711P Series (PanelView Plus) represents Rockwell Automation's primary human-machine interface (HMI) platform deployed across global heavy industry. Installations span petrochemical complexes, nuclear power generation facilities, offshore oil & gas platforms, and continuous-process refineries. The series operates as the operator interface layer within Rockwell's Integrated Architecture, communicating natively with ControlLogix, CompactLogix, and SLC 500 controllers via EtherNet/IP and DH-485. Installed base counts in the hundreds of thousands of units worldwide, making long-term spare parts availability a critical operational concern for plant maintenance teams.

2711P Full Catalog & Functionalities (SKU List)

Logic / Replacement Processor Modules

• 2711P-RP7: PanelView Plus CE logic module, Windows CE runtime, 64 MB RAM, compact flash slot, for 6"–15" terminals
• 2711P-RP8: PanelView Plus 6 logic module, enhanced CE processor, 128 MB RAM, USB host, SD card slot
• 2711P-RP9: PanelView Plus 7 logic module, 1 GHz ARM processor, 512 MB RAM, dual USB, SD slot, capacitive touch support
• 2711P-RP6: PanelView Plus logic module (earlier generation), 32 MB RAM, compact flash, DH-485 and EtherNet/IP support

Display / Terminal Assemblies (Touch & Keypad)

• 2711P-T6C20D: 6.5" color TFT touch terminal, 640×480, EtherNet/IP, DC powered
• 2711P-T7C4D2: 7" widescreen color touch, 800×480, EtherNet/IP + DH-485, DC
• 2711P-T10C4D1: 10.4" color touch terminal, 800×600, EtherNet/IP, DC powered
• 2711P-T12W4D8: 12.1" widescreen touch, 1280×800, EtherNet/IP, DC powered
• 2711P-T15C22D9P: 15" color touch terminal, 1024×768, EtherNet/IP, DC, stainless bezel
• 2711P-B10C4D2: 10.4" color keypad terminal, 800×600, EtherNet/IP + DH-485, DC
• 2711P-B12C4D1: 12.1" color keypad terminal, 800×600, EtherNet/IP, DC powered

Communication & Network Adapter Cards

• 2711P-RN15S: EtherNet/IP communication card, 10/100 Mbps, RJ-45, for 2711P terminals
• 2711P-RN6: DH-485 / RS-232 communication module, serial network interface card
• 2711P-RN8: ControlNet communication card, coax BNC interface, for legacy ControlNet topologies
• 2711P-RN15: EtherNet/IP card (earlier revision), 10/100 Mbps, single port RJ-45

Power Supply & Accessory Modules

• 2711P-RSACDIN: AC power supply adapter, DIN rail mount, 100–240 VAC input for PanelView Plus terminals
• 2711P-RPACDCKIT: AC/DC power conversion kit, field-installable, for panel-mount applications
• 2711P-RY2032: Real-time clock battery replacement module, CR2032 compatible, for 2711P logic boards
