Allen-Bradley 2711P Series Modules – 2711P-T10C4D8

Technical Dossier

Product Details And Specifications

Allen-Bradley 2711P Series Technical Notes

Q: How are RFQ terms confirmed?
A: Quantity, required condition, documentation needs, destination and sourcing route are confirmed during RFQ review before quotation.

The Evolution of 2711P Architecture

The 2711P designation was introduced by Rockwell Automation circa 2007 as the PanelView Plus 6 platform, replacing the legacy PanelView Plus (Classic) units. The architecture is built around an x86-compatible embedded processor running Windows CE 6.0 or Windows Embedded Compact 7, with a resistive or capacitive touchscreen front panel and an integrated DH-485 / EtherNet/IP / DF1 communication stack.

With the PanelView Plus 7 (2711P-T*C4D8 suffix) generation, Rockwell standardized on a 32-bit ARM Cortex-A8 processor, 512 MB RAM, 2 GB internal flash, dual USB 2.0 ports, and a 10/100 Ethernet port. The suffix convention decodes as: C = color display, 4 = 4th-generation hardware revision, D = DC power input, 8 = 8th firmware baseline. Units with the K suffix (e.g., 2711P-T10C4D8K) add a NEMA 4X/IP66 front-panel rating. The transition from PanelView Plus 6 to PanelView Plus 7 introduced capacitive multi-touch, improved display brightness (400 cd/m²), and FactoryTalk View ME v10+ compatibility. Legacy PV+ 6 applications are forward-compatible without recompilation in most cases.

2711P Full Catalog & Functionalities (SKU List)

— Compact Class (3.5" – 6" Display) —

2711P-T4W21D8S: 3.5-in WQVGA color touch, DC, NEMA 4X, EtherNet/IP
2711P-T6C20D8: 5.7-in VGA color touch, DC power, standard bezel, CE7
2711P-T6C20D8S: 5.7-in VGA color touch, DC, NEMA 4X/IP66 front seal
2711P-T6C21D8S: 5.7-in VGA color touch, DC, stainless steel hygienic bezel
2711P-T7C4D8: 7-in WVGA color touch, DC, standard aluminum bezel
2711P-T7C4D8K: 7-in WVGA color touch, DC, NEMA 4X/IP66 rated front panel

— Mid-Range Class (10" Display) —

2711P-T10C4D8: 10.4-in XGA color touch, DC, standard bezel — current page SKU
2711P-T10C4D8K: 10.4-in XGA color touch, DC, NEMA 4X/IP66 front panel
2711P-T10C4A8: 10.4-in XGA color touch, AC power input variant
2711P-T10C4D8S: 10.4-in XGA color touch, DC, stainless steel hygienic bezel
2711P-RDT10C: 10.4-in remote display terminal, thin-client mode, no local processing

— Keypad & Combination Input Class —

2711P-K10C4D8: 10.4-in XGA color, function key + touch hybrid input
2711P-K7C4D8: 7-in WVGA color, function key + touch hybrid input
2711P-K15C4D8: 15-in XGA color, function key + touch hybrid input

— Accessories & Expansion —

2711P-RN15S: EtherNet/IP communication module, DIN-rail mount, remote I/O expansion
2711P-RP8A: Replacement rechargeable battery pack for 2711P terminals

Sourcing Hard-to-Find & Obsolete 2711P Parts

DriveKNMS operates a dedicated lifecycle extension program for the Allen-Bradley 2711P series covering three primary sourcing scenarios:

Q: How is condition confirmed before quotation?
A: Available condition, photos, test records and documentation are checked according to the requested model and sourcing channel before a formal RFQ response.

3. Application-locked legacy units: Some facilities operate FactoryTalk View ME applications compiled against older runtime versions (v5.x, v6.x) incompatible with current-production hardware. DriveKNMS can supply matched hardware-firmware combinations to avoid application re-validation costs under IEC 61511 or FDA 21 CFR Part 11 compliance frameworks.
