ABB AC500 200-Series Modules: 200-CIE, 200-CNT, 200-AO & Full Catalog

Name: ABB AC500 200-Series Modules: 200-CIE, 200-CNT, 200-AO & Full Catalog
Brand: ABB

Model: 200-CIE

Brand ABB

Series Pending

Model 200-CIE

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

ABB AC500 200-Series Technical Notes

The Evolution of AC500 200-Series Architecture

The AC500 platform was introduced by ABB in 2005 as a successor to the CS31 and Advant OCS controller families. The 200-Series CPUs (PM554, PM564, PM572, PM582, PM591, PM592) were positioned between the entry-level 100-Series and the high-performance 600-Series. Early 200-Series hardware used the S500 local I/O bus with a maximum of 10 I/O modules per CPU station. Firmware revisions through 2010–2016 introduced IEC 61131-3 structured text enhancements, expanded memory maps, and SD card data logging. The communication module range expanded significantly with the introduction of the 200-CIE (Ethernet), 200-CNT (Counter), and 200-AO (Analog Output) modules, enabling the 200-Series to interface with SCADA systems via OPC-UA and Modbus TCP without a dedicated gateway. By 2018, ABB began transitioning customers toward the AC500-eCo V3 and AC500-S (safety) variants, though the 200-Series remains in active production support with spare parts availability confirmed through ABB's extended lifecycle program. Compatibility between 200-Series I/O modules and newer PM5xx-ETH CPUs is maintained at the hardware bus level, allowing phased migration without full system replacement.

AC500 200-Series Full Catalog & Functionalities (SKU List)

CPU Modules

PM554-T-ETH: CPU, 256KB RAM, 2x Ethernet, SD slot, AC500 mid-range controller
PM564-T-ETH: CPU, 512KB RAM, dual Ethernet, extended I/O capacity, onboard USB
PM572-ETH: CPU, 1MB RAM, high-speed processing, supports up to 10 S500 I/O modules
PM582-ETH: CPU, 2MB RAM, dual Ethernet, real-time clock, extended program memory
PM591-ETH: CPU, 4MB RAM, PROFINET controller, high-density I/O bus master
PM592-ETH: CPU, 8MB RAM, dual PROFINET, redundancy-ready, top-tier 200-Series

Communication & Interface Modules

200-CIE: Communication Interface Ethernet — Modbus TCP slave, EtherNet/IP adapter, PROFINET IO device
CM572-DP: PROFIBUS DP master/slave communication module, up to 12Mbps
CM574-RS: Serial communication module, RS232/RS485, Modbus RTU master/slave
CM577-ETH: Ethernet communication coupler for remote S500 I/O stations
CM589-PNIO: PROFINET IO controller module, IRT capable, up to 128 IO devices

Digital I/O Modules

DI524: 16x digital inputs, 24VDC, IEC Type 1/3, 0.2ms filter time
DO524: 16x digital outputs, 24VDC, 0.5A per channel, short-circuit protected
DX522: 8x DI + 8x DO, 24VDC, mixed I/O module, compact footprint

Analog I/O Modules

AI523: 8x analog inputs, 0–10V / 0–20mA / 4–20mA, 12-bit resolution
AO523: 4x analog outputs, 0–10V / 4–20mA, 12-bit, individually configurable
200-AO: Analog output expansion module, 4-channel, 16-bit resolution, rail-mount

Counter & Specialty Modules

200-CNT: High-speed counter module, 4-channel, up to 100kHz, encoder interface A/B/Z
DC532: 16x digital I/O, transistor output, 24VDC, high-speed capable

Continue The Model Path

Use system, brand and series routes to compare related published models.

Move from this exact model into the matching system hub, brand archive, model-family archive or lifecycle sourcing route before sending a final RFQ list.
