ABB CP665 Modules: CP665 1SAP565100R0001

Name: ABB CP665 Modules: CP665 1SAP565100R0001
Brand: ABB

Model: CP665 1SAP565100R0001

Brand ABB

Series CP665

Model CP665 1SAP565100R0001

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

ABB CP665 Series Technical Notes

The ABB CP665 series is a line of industrial HMI (Human-Machine Interface) control panels deployed across heavy-process industries including petrochemical refineries, nuclear power facilities, offshore platforms, and continuous-process chemical plants. Built on ABB's AC500 and System 800xA automation architecture, CP665 panels serve as the primary operator interface layer in distributed control system (DCS) and PLC environments where high-resolution visualization, rugged enclosure ratings, and long-term platform stability are mandatory procurement criteria. The 13.3-inch TFT widescreen format, combined with resistive or projected capacitive touch technology, positions the CP665 as a mid-to-large format panel PC suitable for both cabinet-mount and panel-mount installations in ATEX-adjacent control rooms.

The Evolution of CP665 Architecture

The CP665 series succeeded ABB's earlier CP600 and CP620 compact panel families, inheriting the same DIN-rail-compatible form factor while expanding display resolution to 1280x800 WXGA and integrating dual Ethernet ports for redundant network topologies. Early CP665 variants shipped with Windows CE 6.0 as the embedded OS, supporting ABB's Panel Builder 600 (PB600) HMI development environment. Subsequent hardware revisions transitioned to Windows Embedded Compact 7 and later Windows 10 IoT Enterprise LTSC, enabling compatibility with modern OPC UA communication stacks and ABB Ability cloud connectivity modules. The internal CPU architecture migrated from ARM Cortex-A8 (single-core, 600 MHz) in first-generation units to ARM Cortex-A9 dual-core configurations in later revisions, doubling the graphics rendering throughput for trend displays and alarm management screens. Backplane communication with AC500 CPUs is maintained via PROFIBUS DP, Modbus TCP, and EtherNet/IP. Units manufactured before 2018 are now classified as mature/end-of-active-production by ABB; DriveKNMS maintains RFQ-reviewed sourcing status of these legacy variants to support lifecycle extension programs for installed base customers.

CP665 Full Catalog & Functionalities (SKU List)

The following SKUs represent the verified CP665 product range, classified by primary function and hardware configuration:

1SAP565100R0001: CP665, 13.3-inch TFT WXGA touch panel, 600 MHz ARM, Windows CE 6.0, 2x Ethernet, 2x USB, 256 MB RAM
1SAP565200R0001: CP665-WEB, 13.3-inch TFT, web-client HMI variant, thin-client architecture, no local project storage
1SAP565100R0002: CP665 Rev.2, upgraded ARM Cortex-A9 dual-core CPU, Windows Embedded Compact 7, enhanced graphics
1SAP565100R0003: CP665 Rev.3, Windows 10 IoT LTSC, 512 MB RAM, 4 GB eMMC flash, OPC UA client integrated
1SAP565300R0001: CP665-S, stainless steel front bezel variant, IP66 front rating, food and pharma environments
1SAP565400R0001: CP665-TS, projected capacitive multi-touch, glove-compatible, 1280x800 IPS display
1SAP565500R0001: CP665-M, marine-certified variant, DNV GL type approval, vibration-rated mounting
1SAP500100R0001: CP600-eCo, predecessor compact panel, 5.7-inch STN, compatible PB600 project base
1SAP520100R0001: CP620, 5.7-inch TFT, PROFIBUS DP integrated, predecessor to CP665 mid-range
1SAP530100R0001: CP630, 7.5-inch TFT, predecessor series, Windows CE 5.0, single Ethernet
1SAP540100R0001: CP635, 10.4-inch TFT XGA, direct predecessor to CP665, same mounting cutout
1SAP565100R0010: CP665 spare display assembly, 13.3-inch TFT panel replacement unit, field-serviceable
1SAP565100R0020: CP665 power supply board, 24 VDC input, internal DC-DC converter module
1SAP565100R0030: CP665 touch controller PCB, resistive touch interface board, field-replaceable
1SAP565100R0040: CP665 backplane connector kit, 40-pin ribbon cable assembly, revision-matched
1SAP565100R0050: CP665 SD card module, 2 GB industrial-grade, pre-formatted for PB600 runtime
1SAP565100R0060: CP665 mounting clamp set, panel-mount hardware kit, stainless steel, 8-piece
1SAP565100R0070: CP665 protective film kit, anti-glare screen protector, 5-pack, OEM specification
