ABB 3ASD273001B1 Power Measuring Unit

Technical Dossier

Product Details And Specifications

ABB YPG111A Series Technical Notes

The ABB YPG111A series, identified by the base part number 3ASD273001B1, is a Power Measuring Unit designed for integration within ABB's UNITROL excitation control and Symphony Plus distributed control system (DCS) platforms. These modules are deployed in high-criticality industrial environments including thermal and nuclear power generation facilities, petrochemical refineries, offshore platforms, and large-scale chemical processing plants. The YPG111A performs real-time measurement of active power (P), reactive power (Q), and power factor (cos φ), providing essential feedback signals to the excitation regulator and plant-level SCADA systems. Its role in generator excitation control makes it a safety-relevant component in grid-connected generation assets worldwide. ABB's installed base for this module spans multiple continents, with significant deployment density in European and Asian power utility infrastructure.

YPG111A Full Catalog & Functionalities (SKU List)

The following SKUs represent the verified module range associated with the ABB YPG111A power measurement and UNITROL excitation I/O ecosystem. Each entry reflects a distinct hardware variant or functionally related module used within the same control chassis:

YPG111A / 3ASD273001B1: Power measuring unit; measures P, Q, cos φ for excitation control feedback.
YPG111B / 3ASD273001B2: Revised power measuring unit with extended voltage input range (up to 690 V AC).
YPG112A / 3ASD273002B1: Dual-channel power measuring unit for parallel generator configurations.
YPT111A / 3ASD271001B1: Voltage transducer module; three-phase AC voltage measurement input card.
YPT112A / 3ASD271002B1: Current transducer module; three-phase AC current measurement input card.
YPC111A / 3ASD272001B1: Analog output module; 4–20 mA signal conditioning for SCADA interface.
YPC112A / 3ASD272002B1: Digital output module; relay contact outputs for protection relay interfacing.
YPD111A / 3ASD274001B1: Excitation field current measurement module; DC shunt input type.
YPD112A / 3ASD274002B1: Excitation voltage measurement module; high-impedance DC input.
YPR111A / 3ASD275001B1: AVR reference input module; setpoint signal conditioning card.
YPR112A / 3ASD275002B1: Manual control reference module; backup voltage regulation input.
YPK111A / 3ASD276001B1: Communication interface module; Modbus RTU / PROFIBUS DP gateway.
YPK112A / 3ASD276002B1: Ethernet communication module; IEC 61850 GOOSE messaging support.
YPS111A / 3ASD277001B1: Power supply module; 24 V DC regulated output for I/O backplane.
YPS112A / 3ASD277002B1: Redundant power supply module; hot-swap capable, N+1 configuration.
YPF111A / 3ASD278001B1: Field flashing module; initial excitation bootstrap for brushless generators.
YPG113A / 3ASD273003B1: Three-winding transformer power measuring unit; for unit transformer monitoring.
YPM111A / 3ASD279001B1: Protection interface module; ANSI 40 / 78 loss-of-excitation relay input conditioning.

Quality Control for the YPG111A Range

The YPG111A presents specific test challenges due to its mixed-signal architecture: the module simultaneously handles high-voltage AC measurement inputs (up to 500 V AC line-to-line via internal PT) and low-level analog signal outputs on the same PCB. DriveKNMS applies the following test protocol to all YPG111A units prior to dispatch: (1) Visual inspection under 10× magnification for PCB delamination, capacitor bulge, and solder joint integrity on the backplane connector array. (2) Dielectric withstand test at 2 kV AC for 60 seconds between measurement input terminals and logic supply rails. (3) Functional calibration verification: three-phase voltage and current signals are injected at 100%, 75%, and 50% of rated input using a precision power source (accuracy class 0.05), and output signals are verified against factory tolerance bands. (4) Backplane communication test: the module is installed in a UNITROL-compatible test chassis and polled via the internal bus to confirm register map integrity and response latency within specification. (5) Thermal soak: 4-hour burn-in at 55°C ambient to screen latent component failures. Units that pass all five stages are issued a DriveKNMS test certificate and shipped with anti-static packaging and desiccant.
