Woodward 5466 Series Modules – 5466-1036

Technical Dossier

Product Details And Specifications

Woodward 5466 Series Technical Notes

The Evolution of 5466 Series Architecture

The 5466 Series was introduced as part of Woodward's transition from analog governor platforms (505 Series) to fully digital, microprocessor-based control in the late 1980s and early 1990s. Early revisions used parallel backplane communication with proprietary Woodward bus protocols, limiting interoperability to same-generation hardware. Mid-generation revisions introduced enhanced EEPROM-based parameter storage, replacing battery-backed RAM and significantly improving configuration retention across power cycles.

Q: How are RFQ terms confirmed?
A: Quantity, required condition, documentation needs, destination and sourcing route are confirmed during RFQ review before quotation.

5466 Series Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly sourced modules within the Woodward 5466 Series. Modules are classified by functional category.

Digital Control / CPU Modules

• 5466-1036: Digital Control Module; primary CPU/controller board for MicroNet governor systems, handles closed-loop speed and load control logic.
• 5466-1037: Digital Control Module variant; alternate firmware revision for 5466-1036, used in specific OEM turbine configurations.
• 5466-1038: Digital Control Module; enhanced memory variant supporting extended parameter sets for multi-valve steam turbine applications.
• 5466-1039: Digital Control Module; dual-channel configuration for redundant control architectures in critical process applications.

Analog Input (AI) Modules

• 5466-1040: Analog Input Module; 8-channel, 4–20 mA / 0–10 V configurable inputs for process variable acquisition (pressure, temperature, flow).
• 5466-1041: Analog Input Module; high-resolution 16-bit ADC variant for precision measurement in turbine inlet/exhaust monitoring.
• 5466-1042: Analog Input Module; isolated channel design for high-common-mode-voltage environments in generator excitation monitoring.

Analog Output (AO) Modules

• 5466-1050: Analog Output Module; 4-channel, 4–20 mA output for actuator positioning signals (fuel control valves, IGV actuators).
• 5466-1051: Analog Output Module; high-current output variant for direct electro-hydraulic actuator drive without external signal conditioning.

Digital Input (DI) Modules

• 5466-1060: Digital Input Module; 16-channel, 24 VDC discrete input for trip signals, permissive interlocks, and operator pushbutton interfaces.
• 5466-1061: Digital Input Module; 32-channel high-density variant for large I/O count applications in combined-cycle plant configurations.
• 5466-1062: Digital Input Module; AC-input compatible (110/220 VAC) for legacy field device integration without relay interposing.

Digital Output (DO) Modules

• 5466-1070: Digital Output Module; 16-channel relay output, rated 2A per channel, for solenoid valve and alarm annunciator drive.
• 5466-1071: Digital Output Module; solid-state output variant for high-cycle-rate applications requiring extended contact life.

Communication & Power Modules

• 5466-1080: Communication Adapter Module; Modbus RTU / RS-485 interface for SCADA and DCS integration without gateway hardware.
• 5466-1090: Power Supply Module; 24 VDC regulated backplane power, dual-redundant input, for MicroNet chassis power distribution.
• 5466-1091: Power Supply Module; extended input range (18–36 VDC) variant for battery-backed UPS-fed control panels.

Sourcing Hard-to-Find & Obsolete 5466 Series Parts

Q: How is condition confirmed before quotation?
A: Available condition, photos, test records and documentation are checked according to the requested model and sourcing channel before a formal RFQ response.

Quality Control for the 5466 Series Range

The 5466 Series presents specific quality verification challenges due to its backplane-coupled architecture and proprietary Woodward communication bus. DriveKNMS applies a structured test protocol to all 5466 modules prior to shipment.
