Mitsubishi MR-MC01-S100 MR-MC01 DL240 F2-08TRS D2-FILL D2-06BDC1-1 6151654230 EME35-10J PCB ASSY

Technical Dossier

Product Details And Specifications

Mitsubishi MR-MC01 Series: Comprehensive Module Range and Technical Overview

The Mitsubishi Electric MR-MC01 series represents a class of motion controller and PCB assembly modules deployed extensively across global heavy industry sectors, including petrochemical refineries, nuclear power auxiliary systems, automotive stamping lines, and continuous-process chemical plants. The MR-MC01-S100 is a motion control option card designed to interface with Mitsubishi MELSERVO and MELSEC platforms, enabling multi-axis synchronization, cam profile execution, and high-speed position latch functions. Its PCB assembly format (PCB ASSY) indicates a board-level component used in OEM machine rebuilds, servo amplifier repairs, and control panel retrofits. Companion parts in this listing — including the DL240, F2-08TRS, D2-FILL, D2-06BDC1-1, 6151654230, and EME35-10J — span Mitsubishi's MELSEC F2/D2 I/O module families and third-party PCB sub-assemblies, reflecting the mixed-platform reality of long-running industrial installations.

The Evolution of MR-MC01 Architecture

The MR-MC01 option card was introduced as part of Mitsubishi's MR-J2S and MR-J3 servo amplifier ecosystem, providing a dedicated motion controller interface that offloaded trajectory calculation from the main PLC CPU. Early revisions (pre-2005) operated over a proprietary SSCNET (Servo System Controller NETwork) bus at 4 Mbps. The MR-MC01-S100 variant introduced enhanced synchronization logic and expanded cam table memory, making it compatible with MR-J3-B amplifiers operating on SSCNET III (optical, 50 Mbps). As Mitsubishi transitioned to the MR-J4 and MR-J5 platforms (post-2012), the MR-MC01 line entered a maintenance-only lifecycle. Current installations running MR-MC01-S100 in legacy machines face a compatibility boundary: MR-J4 amplifiers require the MR-MC01-B or the iQ-R Motion CPU (R16MTCPU/R32MTCPU) as replacements. The F2 and D2 series I/O modules (F2-08TRS, D2-FILL, D2-06BDC1-1) belong to Mitsubishi's earlier MELSEC F2/D2 programmable controller families, which reached end-of-manufacture in the early 2000s. These modules remain in service in legacy OEM equipment and require sourcing from authorized aftermarket distributors.

MR-MC01 Full Catalog & Functionalities (SKU List)

The following SKUs represent verified models within the Mitsubishi MR-MC01 motion controller option card family and associated MELSEC F2/D2 I/O module range. Each entry reflects a distinct functional role within its respective control architecture.

MR-MC01-S100: Motion controller option card, SSCNET III, multi-axis cam sync, for MR-J3-B series amplifiers.
MR-MC01: Base motion controller option card, SSCNET I/II, compatible with MR-J2S servo amplifiers.
MR-MC01-B: Enhanced motion option card for MR-J4-B amplifiers, SSCNET III/H optical bus.
MR-MC01-A: Analog command input variant of the MR-MC01 motion option card.
DL240: PCB sub-assembly / driver board used in Mitsubishi servo amplifier and spindle drive repair applications.
F2-08TRS: MELSEC F2 series transistor output module, 8-point, sink type, 24VDC load.
F2-08TS: MELSEC F2 series transistor output module, 8-point, source type variant.
F2-08A: MELSEC F2 analog input module, 8-channel, used in legacy process control loops.
F2-32DP: MELSEC F2 32-point digital I/O mixed module for compact panel installations.
D2-FILL: MELSEC D2 series filler/blank module, used to occupy unused backplane slots and maintain bus integrity.
D2-06BDC1-1: MELSEC D2 series 6-slot base unit with DC power input, revision 1, for D2 CPU and I/O module mounting.
D2-08ND3: MELSEC D2 8-point DC input module, 24VDC, sink/source compatible.
D2-08TD1: MELSEC D2 8-point transistor output module, 12-24VDC, sink type.
D2-16ND3-2: MELSEC D2 16-point DC input module, high-density, 24VDC.
D2-RMSM: MELSEC D2 remote I/O master module for distributed I/O expansion over RS-485.
6151654230: OEM PCB assembly part number (manufacturer-specific), used in servo drive or CNC control board repair; cross-reference required for exact platform identification.
EME35-10J: PCB assembly sub-module, identified in Mitsubishi-compatible CNC or drive repair applications; board-level component for authorized repair centers.

Sourcing Hard-to-Find & Obsolete MR-MC01 Parts

The MR-MC01, F2, and D2 series have all reached end-of-manufacture status with Mitsubishi Electric. New production stock is no longer available through standard distribution channels. DriveKNMS maintains a dedicated inventory of pulled, tested, and refurbished units sourced from decommissioned equipment, factory overstock, and authorized repair returns. For PCB-level components such as the DL240, 6151654230, and EME35-10J, DriveKNMS provides board-level inspection and functional verification before shipment. Customers operating legacy machines with no viable upgrade path can request long-term supply agreements covering annual demand forecasting, reserved stock allocation, and priority fulfillment. Cross-reference services are available to identify functional equivalents where direct replacements are no longer obtainable.

Quality Control for the MR-MC01 Range

PCB assemblies and motion controller option cards in the MR-MC01 family undergo a structured test protocol at DriveKNMS before dispatch. Backplane bus integrity is verified using dedicated SSCNET I/II/III loopback test fixtures. Option card firmware revision is read and logged against known-good revision tables for MR-J2S and MR-J3 compatibility. F2 and D2 I/O modules are tested under load using programmable DC sources and electronic loads to verify output switching, input threshold voltage, and isolation resistance. PCB sub-assemblies (DL240, EME35-10J, 6151654230) are inspected under 10x magnification for solder joint integrity, component substitution, and corrosion, followed by powered functional test where test fixtures are available. All units are shipped with a test report and 12-month warranty against defects in materials and workmanship.
