ABB Robot TZ865A BU768A390G51 Control Board

Name: ABB Robot TZ865A BU768A390G51 Control Board
Brand: ABB

Model: TZ865A BU768A390G51

Brand ABB

Series Pending

Model TZ865A BU768A390G51

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

ABB Robot TZ865A BU768A390G51 Series Technical Notes

The ABB Robot TZ865A series, represented by the BU768A390G51 control board variant, is a core component within ABB's industrial robot controller ecosystem. These boards are deployed across heavy-industry sectors including automotive body-in-white assembly, chemical plant material handling, nuclear facility maintenance robotics, and refinery pipeline inspection systems. The TZ865A platform underpins ABB's IRC5 and S4C+ controller generations, providing the backplane logic, axis control arbitration, and fieldbus interface management that governs multi-axis robot motion. Installed base counts in the tens of thousands globally, with particularly high concentrations in European and East Asian manufacturing corridors.

The Evolution of TZ865A Architecture

The TZ865A control board lineage traces to ABB's transition from the S4 to S4C+ controller platform in the late 1990s. Early S4-generation boards used discrete analog servo amplifier logic with limited fieldbus support. The TZ865A introduced a unified digital backplane architecture compatible with DeviceNet, PROFIBUS-DP, and ABB's proprietary RAPID motion bus. The BU768A sub-series (including BU768A390G51) represents a mid-generation revision that added enhanced ESD protection layers and revised EEPROM addressing for expanded program memory. Subsequent generations migrated toward the IRC5 DSQC series (e.g., DSQC639, DSQC643), which replaced TZ865A boards in new production from approximately 2005 onward. As a result, the TZ865A/BU768A family is now firmly in the mature-to-end-of-life phase. ABB no longer manufactures these boards as standard catalog items; procurement relies entirely on aftermarket channels, certified repair facilities, and specialist distributors such as DriveKNMS.

TZ865A Full Catalog & Functionalities (SKU List)

The following SKUs represent verified components within the ABB Robot TZ865A / BU768A control board family and associated S4C+ controller modules. Each entry reflects a distinct functional role within the robot controller architecture.

TZ865A BU768A390G51: Main robot control board, S4C+ backplane logic and axis arbitration unit.
TZ865A BU768A390G52: Revised main control board with updated firmware EEPROM addressing.
TZ865A BU768A390G53: Control board variant with extended temperature tolerance for foundry environments.
TZ865A BU768A390G54: High-vibration rated control board for press-shop and stamping line robots.
TZ865A BU768A390G55: Control board with dual-channel safety relay interface for ISO 10218 compliance.
BU768A390G51: Base board assembly without TZ865A carrier frame; used in board-swap repair kits.
DSQC223 / TZ865A: Axis computer board, manages interpolation for up to 6 servo axes.
DSQC224: I/O board, 16 DI / 16 DO, 24 VDC, compatible with TZ865A backplane.
DSQC225: Analog I/O board, 4 AI / 4 AO, ±10 V range, S4C+ rack mount.
DSQC226: Serial measurement board, encoder feedback processing for axes 1–6.
DSQC228: PROFIBUS-DP master/slave adapter, integrates with TZ865A fieldbus slot.
DSQC229: DeviceNet scanner board, 64-node capacity, S4C+ controller slot.
DSQC230: Power distribution board, 24 VDC regulated output for I/O rack.
DSQC231: Teach pendant interface board, FlexPendant signal routing.
DSQC232: Safety board, emergency stop chain monitoring and axis enable logic.
DSQC233: Ethernet board, 10/100 Mbit RJ45, robot network integration.
DSQC256A: Main computer board (IRC5 transition variant), compatible with select TZ865A chassis.
3HAC026254-001: Replacement EEPROM module for TZ865A BU768A series boards.
3HAC025338-001: Backplane connector repair kit for S4C+ TZ865A rack.

Continue The Model Path

Use system, brand and series routes to compare related published models.

Move from this exact model into the matching system hub, brand archive, model-family archive or lifecycle sourcing route before sending a final RFQ list.
