Siemens SIMATIC IPC477D Modules: 6AV7240-0HC07-0PA0 Main Board

Name: Siemens SIMATIC IPC477D Modules: 6AV7240-0HC07-0PA0 Main Board
Brand: Siemens

Model: IPC477D 6AV7240-0HC07-0PA0

Brand Siemens

Series Pending

Model IPC477D 6AV7240-0HC07-0PA0

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Siemens SIMATIC IPC477D Series Technical Notes

The Siemens SIMATIC IPC477D is a panel-integrated industrial PC platform deployed across heavy-process industries including petrochemical refineries, nuclear power generation facilities, offshore platforms, and large-scale chemical plants. Built on the SIMATIC IPC product line, the IPC477D integrates computing hardware directly into operator panel enclosures, eliminating the need for separate cabinet-mounted PCs. Its rugged design — rated for continuous 24/7 operation in environments with elevated vibration, dust ingress, and wide temperature fluctuations — has made it a standard HMI computing platform in SIMATIC PCS 7 and WinCC SCADA architectures globally. The 6AV7240-0HC07-0PA0 main board is a core replacement component for this platform, directly governing CPU processing, memory interfacing, and backplane communication.

The Evolution of IPC477D Architecture

The SIMATIC IPC477 product line was introduced as a successor to the IPC477C, transitioning from older Intel Core 2 Duo platforms to Intel Core i-series (Sandy Bridge / Ivy Bridge generation) processors. The IPC477D revision introduced improved thermal management, updated chipset compatibility (Intel QM77 / HM76), and expanded RAM support up to 16 GB DDR3. Display interface options evolved from single VGA outputs to dual-head configurations supporting DVI-I and DisplayPort. The platform supports Windows 7 Professional (32/64-bit), Windows Embedded Standard 7, and Windows 10 IoT Enterprise — with Siemens providing extended lifecycle support agreements for legacy OS deployments in regulated industries. Compatibility with SIMATIC WinCC V7.x and PCS 7 V8.x/V9.x is formally documented. As the IPC477D has entered its mature/end-of-active-production phase, long-term maintenance support (LTMS) contracts and third-party spare parts sourcing have become the primary supply channels for installed base operators.

SIMATIC IPC477D Full Catalog & Functionalities (SKU List)

The following SKUs represent the verified IPC477D product range, organized by functional category.

Panel PC Units (Complete Systems)

6AV7240-0BC07-0PA0: IPC477D 15" TFT, Core i3-3120M, 4 GB RAM, no HDD, Win7 Emb.
6AV7240-0BC17-0PA0: IPC477D 15" TFT, Core i3-3120M, 4 GB RAM, 320 GB HDD, Win7 Pro.
6AV7240-0DC07-0PA0: IPC477D 15" TFT, Core i5-3610ME, 4 GB RAM, no HDD, Win7 Emb.
6AV7240-0DC17-0PA0: IPC477D 15" TFT, Core i5-3610ME, 4 GB RAM, 320 GB HDD, Win7 Pro.
6AV7240-0HC07-0PA0: IPC477D 19" TFT, Core i7-3612QE, 8 GB RAM, no HDD — Main Board assembly.
6AV7240-0HC17-0PA0: IPC477D 19" TFT, Core i7-3612QE, 8 GB RAM, 320 GB HDD, Win7 Pro.
6AV7241-0BC07-0PA0: IPC477D 15" TFT, Core i3, stainless front panel, IP65 rated.
6AV7241-0DC07-0PA0: IPC477D 15" TFT, Core i5, stainless front panel, IP65 rated.
6AV7241-0HC07-0PA0: IPC477D 19" TFT, Core i7, stainless front panel, IP65 rated.

Spare Parts & Replacement Components

6AV7671-1EX00-0AX0: Replacement HDD 320 GB SATA for IPC477D/IPC477C series.
6AV7671-1EX10-0AX0: Replacement SSD 80 GB SATA for IPC477D series.
6AV7671-5QE00-0AA0: Replacement fan unit for IPC477D thermal management.
6AV7671-8BE00-0AA0: Replacement power supply unit 24 VDC for IPC477D.
6AV7671-8XE00-0AA0: Replacement battery (CMOS/RTC) for IPC477D mainboard.
6AV7240-0BC00-0AA0: Replacement front panel / touch bezel assembly, 15" variant.
6AV7240-0HC00-0AA0: Replacement front panel / touch bezel assembly, 19" variant.
6ES7648-0DC60-0AA0: Compatible CFast card 8 GB for IPC477D OS image storage.

Quality Control for the IPC477D Range

IPC477D main boards and sub-assemblies undergo a structured inspection and functional verification process prior to dispatch. Each unit is visually inspected for PCB damage, capacitor condition, and connector integrity. Main boards are bench-tested under simulated load conditions, with BIOS POST verification, memory slot testing (all channels), and storage interface (SATA/CFast) continuity checks performed. Units with integrated display controllers are tested against known-good panel assemblies to verify signal output on all active display ports. Power supply units are load-tested at rated output (24 VDC input / internal DC-DC conversion) and measured for ripple within Siemens-specified tolerances. All tested units are assigned a condition grade (Refurbished / Tested-Used / New Surplus) and shipped with an inspection report on request.
