Mitsubishi MELSEC F1 Series: Comprehensive Module Range and Technical Overview

The Mitsubishi MELSEC F1 Series is a compact, fixed-configuration programmable logic controller platform developed by Mitsubishi Electric for small-to-medium discrete automation applications. Introduced in the early 1980s as a successor to the F Series, the F1 line achieved widespread deployment across global heavy industry sectors including petrochemical processing plants, nuclear facility auxiliary systems, automotive assembly lines, and refinery utility control loops. Its relay-output and transistor-output base units, combined with a straightforward ladder-logic programming model, made it the default entry-level PLC in Asian and European industrial markets throughout the 1980s and into the mid-1990s. Installed base estimates place the F1 Series among the highest-volume Mitsubishi PLC platforms ever produced, with units still operational in legacy plant environments requiring long-term maintenance support.

📩 Looking for a specific F1 Series model? Send your parts list to: sale@driveknms.com

The Evolution of F1 Series Architecture

The MELSEC F1 Series was designed around a fixed I/O architecture, meaning the CPU, power supply, and I/O points are integrated into a single base unit rather than distributed across a backplane. This design reduced wiring complexity and panel footprint at the cost of expandability. The F1 platform introduced the FX programming protocol predecessor, using a dedicated handheld programmer (F1-20P) or the early MEDOC DOS-based software environment.

The F1 Series succeeded the original MELSEC F Series and was itself succeeded by the MELSEC F2 and subsequently the long-running MELSEC FX0, FX1, FX2, FX3, and FX5 families. Compatibility between F1 and later FX-series programs is not direct — ladder programs require manual conversion due to instruction set differences. This architectural discontinuity is the primary driver of demand for original F1 spare units, as plant operators running F1-based systems cannot perform a drop-in CPU swap with modern FX5U hardware without full re-engineering of the control program and I/O wiring.

The F1 Series entered end-of-life (EOL) status with Mitsubishi Electric, meaning no new production runs are scheduled and official factory support has been discontinued. Units are sourced exclusively through the secondary market, specialist distributors, and MRO (Maintenance, Repair & Operations) suppliers.

F1 Series Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly traded models within the Mitsubishi MELSEC F1 Series. Units are categorized by output type and I/O count.

Relay Output Base Units (MR Suffix)

• F1-12MR: 12-point fixed I/O base unit, 6 DC inputs / 6 relay outputs, 100–240V AC power supply, compact DIN-rail mount.
• F1-20MR: 20-point fixed I/O, 12 DC inputs / 8 relay outputs, AC-powered, standard panel mount format.
• F1-30MR: 30-point fixed I/O, 16 DC inputs / 14 relay outputs, AC-powered, extended program capacity.
• F1-40MR: 40-point fixed I/O, 24 DC inputs / 16 relay outputs, highest I/O count in the relay-output F1 range.
• F1-12MR-ES: Export/special variant of the F1-12MR with modified power supply specification for specific regional voltage standards.
• F1-20MR-ES: Export variant of the F1-20MR, equivalent I/O configuration with regional power compliance.

Transistor Output Base Units (MT Suffix)

• F1-12MT: 12-point fixed I/O, 6 DC inputs / 6 transistor (NPN sink) outputs, 24V DC power supply, high-speed output capability.
• F1-20MT: 20-point fixed I/O, 12 DC inputs / 8 transistor outputs, DC-powered, suited for high-cycle-rate actuator control.
• F1-30MT: 30-point fixed I/O, 16 DC inputs / 14 transistor outputs, DC-powered.
• F1-40MT: 40-point fixed I/O, 24 DC inputs / 16 transistor outputs, maximum I/O in the transistor-output F1 range.

Expansion & Peripheral Modules

• F1-8EX: 8-point DC input expansion module, connects to F1 base unit via dedicated expansion connector.
• F1-8EYR: 8-point relay output expansion module, extends relay output capacity of any F1 base unit.
• F1-8EYT: 8-point transistor output expansion module, NPN sink type.
• F1-8AD: 8-channel analog input module, 0–10V DC or 4–20mA selectable per channel, connects via F1 expansion bus.
• F1-2DA: 2-channel analog output module, 0–10V DC or 4–20mA output, used for setpoint transmission to drives and valves.
• F1-20P: Handheld programmer unit, dedicated to F1 Series ladder program entry, monitoring, and forced I/O operations. Not a control module but an essential maintenance tool for F1 installations.

Sourcing Hard-to-Find & Obsolete F1 Series Parts

DriveKNMS maintains a dedicated inventory channel for Mitsubishi MELSEC F1 Series units sourced from decommissioned plant equipment, controlled-environment storage, and verified secondary-market suppliers. Because the F1 Series is fully discontinued at the OEM level, procurement lead times through standard distribution channels are indefinite. DriveKNMS addresses this gap through the following operational protocols:

• Standing buy program for F1 units recovered from plant shutdowns and equipment auctions globally.
• Pre-shipment functional verification on all relay and transistor output base units.
• Cross-reference service: if your required F1 model is unavailable, DriveKNMS will identify the closest functional equivalent within the F1 range or advise on FX-series migration options.
• Batch procurement support for maintenance departments requiring multiple units for critical spares inventory.

📩 Submit your F1 Series requirements to sale@driveknms.com with model number, quantity, and required delivery timeline.

Quality Control for the F1 Series Range

F1 Series base units present specific testing challenges due to their integrated architecture. The CPU, power supply, and I/O circuits share a single PCB assembly, meaning a fault in any subsystem requires evaluation of the complete unit. DriveKNMS applies the following test procedures to all F1 Series stock:

• Power supply verification: Input voltage range confirmation (AC or DC depending on model), output rail measurement at 5V DC logic supply and 24V DC sensor supply where applicable.
• CPU execution test: A standardized ladder program is loaded via F1-20P programmer to verify scan cycle execution, timer/counter function, and program memory retention.
• Input circuit test: Each DC input point is individually energized and verified for correct state registration in the CPU data register.
• Output circuit test: Relay output contacts are tested for continuity under load; transistor outputs are tested for correct switching and leakage current within specification.
• Battery and memory retention check: Program retention is verified after a controlled power cycle to confirm internal battery condition and EEPROM/RAM integrity.
• Units failing any test stage are quarantined, documented, and either repaired by component-level rework or scrapped — they are not returned to saleable inventory.
